ABB 3BSE018741R15 Cable with plug connector

From: | Author:Wang | Time :2024-11-22 | 91 visit: | Share:

ABB 3BSE018741R15 Cable with plug connector

Cooling fans
Fan assignment for DCS880
b = Bridge type
d = Rated AC voltage
Fan cable sizes and tightening torque connected at the fan terminals
Fan terminals are X52 for H4, X2 for H5/H6 and U1, V1, W1 for H7/H8.
b = Bridge type
d = Rated AC voltage
Converter type Size Configuration Fan type Airflow built in [m³/h]
DCS880-S0b-0045-04/05 ...
DCS880-S0b-00100-04/05
H1 1 1 x 3110UL 57
DCS880-S0b-0135-04/05 ...
DCS880-S0b-0300-04/05
H2 2 2 x AFB122 170
DCS880-S01-0290-06
DCS880-S02-0320-06
DCS880-S0b-0315-04/05 ...
DCS880-S0b-0450-04/05
H3
DCS880-S0b-0470-04/05 ...
DCS880-S0b-0520-04/05
3 2 x 3110UL
2 x AFB122
255
DCS880-S01-0590-06
DCS880-S02-0650-06
DCS880-S0b-0610-04/05 ...
DCS880-S0b-0820-04/05
H4 4 1 x W2E200
230 V; 1
388
DCS880-S0b-0900-04/05 ...
DCS880-S0b-1000-04/05
1 x W2E250
230 V; 1
425
DCS880-S0b-1190-04/05 H5 5 R2E250-RB
230 V; 1
800
DCS880-S0b-0900-0dX0 ...
DCS880-S0b-2000-0dX0
H6
(classic)
850
DCS880-S0b-0900-0dXB ...
DCS880-S0b-2000-0dXB
H6
(ErP fan)
5 R2E250-RE04-10
230 V; 1
850
DCS880-S0b-1900-0d ...
DCS880-S0b-3000-0d
H7 6 GR28C-2DK
400 V / 500 V @ 50 Hz
or
460 V @ 60 Hz
1700
DCS880-S0b-2050-dd ...
DCS880-S0b-5200-dd
H8 7 GR35C-2DD
400 V @ 50 Hz or
460 V @ 60 Hz
4500
Converter type Flexible cable Solid cable
max [mm²] Torque [Nm] max [mm²] Torque [Nm]
DCS880-S0b-0610-dd ...
DCS880-S0b-1000-dd
0.5 … 1.5 0.5 … 0.6 0.5 … 1.0 0.5 … 0.6
DCS880-S0b-1190-dd …
DCS880-S0b-2000-dd
0.5 … 1.5 0.5 … 0.6 0.5 … 1.0 0.5 … 0.6
DCS880-S0b-1900-dd ...
DCS880-S0b-3000-dd
0.5 … 1.5 Push in 0.5 … 1.5 Push in
DCS880-S0b-2050-dd ...
DCS880-S0b-5200-dd

0.5 … 1.5 0.6 … 0.8 0.5 … 1.5 0.6 … 0.8

Fan Data for DCS880 (H1 ... H4)

Fan connection for DCS880 (H1 ... H4)
Fan 3110UL AFB122 W2E200 W2E250
Rated voltage [VAC] 24 V internal 24 V internal 230; 1~ 230; 1~
Tolerance [%] +6 / -10 +6 / -10
Frequency [Hz] 50 60 50 60
Power consumption [W] 64 80 135 185
Current consumption [A] 0.29 0.35 0.59 0.82
Blocking current [A] < 0.7 < 0,8 < 0.9 < 0.9
Air flow [m3/h] freely blowing 50 190 925 1030 1835 1910
Max. ambient temperature [° C] < 70 < 70 < 75 60
Useful lifetime of grease 70,000
h/25°
100,000
h/25°
appr.
45,000 h/60°
appr.
40,000 h
Protection Internal temperature detectors
|---------------------- Terminals are located on top of the converter housing ---------------------|
Converter housing
