ABB 5SHY5045L0020 SCR control unit module

From: | Author:Wang | Time :2024-11-25 | 205 visit: | 🔊 Click to read aloud ❚❚ ▶ | Share:

ABB 5SHY5045L0020 SCR control unit module

What this chapter contains
This chapter describes the construction and operating principle of the drive in short.
ACS800-04/U4 product overview
The ACS800-04/U4 is an IP00 drive module for controlling AC motors. It is to be
installed into a cabinet by the customer with base or wall fastening. The input cable
terminals are located at the top of the unit whereas the motor cable terminals are
located at the left- or right-hand side of the unit. The unit is delivered pre-assembled

with mounting pedestal and output busbars.
The ACS800-04M is delivered as non-pre-assembled kits, which provide more

alternatives in assembling the units than the basic ACS800-04.
Example configurations
Motor and brake busbars on the
right-hand long side of the module
and DC busbars on the left-hand side
Output busbars on the short
side of the module
Motor and brake busbars on the
left-hand long side of the module
and DC busbars on the right-hand side
Frame size R8
Output busbars on the short
side of the module
Frame size R7
Frame size R7 with bottom exit
(optional top entry busbar
shroud and bottom exit shroud
included). Output busbars are
located at the base of the
module.


The type designation label includes an IEC and NEMA rating, C-UL US, and CSA
markings, a type code and a serial number, which allow individual recognition of
each unit. The first digit of the serial number refers to the manufacturing plant. The
next four digits refer to the unit’s manufacturing year and week respectively. The
remaining digits complete the serial number so that there are no two units with the
same serial number.
The type designation label is located on the front cover and the serial number label
inside the unit. Example labels are shown below.
The type code contains information on the specifications and configuration of the
drive. The first digits from left express the basic configuration (for example,
ACS800-04-0170-5). The optional selections are given thereafter, separated by plus
signs (for example, +E202). The main selections are described below. Not all
selections are available for all types. For more information, refer to ACS800
Ordering Information (3AFY64556568, available on request).
Type code for ACS800-04 and ACS800-U4 pre-assembled units
Selection Alternatives
Product series ACS800 product series
Type 04 Drive module. When no options are selected: 6-pulse diode input bridge, IP00, top
entry of cables, side exit, RDCU drive control unit, no control panel, no EMC filter,
Standard Control Program, pedestal with output on the long side, output busbar set
for motor, base and wall mounting brackets, one set of manuals. Pre-assembled unit.
U4 Drive module (USA). When no options are selected: 6-pulse diode bridge, UL open
type, open chassis, top entry of cables, side exit, no control panel, no EMC filter, US
version of the Standard Control Program (three-wire start/stop as default setting),
common mode filter in frame size R8, pedestal with output on the long side, output
busbar set for motor, base and wall mounting brackets, one set of manuals.
Size Refer to Technical data: IEC data or NEMA data.
Voltage range
(nominal rating in bold)
2 208/220/230/240 VAC
3 380/400/415 VAC
5 380/400/415/440/460/480/500 VAC
7 525/575/600/690 VAC
Option codes (+ codes)
Resistor braking D150 brake chopper and busbars for brake resistor and DC connection
Filter E210 EMC/RFI filter for second environment TN/IT (grounded/ungrounded) system
E208 common mode filter
Pedestal and output
busbars
0H354 no pedestal
Control panel J400 CDP 312R control panel including a 3-metre panel connection cable
J410 RPMP-11 control panel mounting platform kit including a 3-metre panel connection
cable but no control panel
J413 RPMP-21 control panel holder
Fieldbus K... Refer to ACS800 Ordering Information (3AFY64556568).
I/O L...
Control program N...
Language of manual R...
Specialities P901 coated boards
P904 extended warranty
Safety features Q950 Prevention of unexpected start-up (not to be used with +Q967), including 500 mm
(19.68 in.) cable outside the drive module in frame size R7, 600 mm (23.62 in.) cable
outside the drive module in frame size R8.
Q967 Safe torque off (STO) (not to be used with +Q950), including 500 mm (19.68 in.) cable
outside the drive module in frame size R7, 600 mm (23.62 in.) cable outside the drive
module in frame size R8.
