ABB CI810B DCS programmable communication unit

From: | Author:Wang | Time :2024-11-26 | 69 visit: | Share:

ABB CI810B DCS programmable communication unit

Table 14 Disturbance recorder
Table 15 Interbay bus protocols
Analog channel Recording period
Sample rate selectable
Options 4 currents
or
9 currents
4 currents
and
5 voltages
802 Hz (16.7 Hz)
2400 Hz (50 Hz)
2880 Hz (60 Hz)
401 Hz (16.7 Hz)
1200 Hz (50 Hz)
1440 Hz (60 Hz)
600 Hz (50 Hz)
720 Hz (60 Hz)
Standard X X*) 1.5 s 3 s 6 s
Option 1 X X 6 s 12 s 24 s
Option 2 X X 10 s 20 s 40 s
Number of disturbance records = total recording time / set recording period (max.15)
Independent settings for pre-fault and post-fault period (min. setting 200 ms).
Format: COMTRADE 91 and COMTRADE 99
*) in Standard, voltage channels are recorded, if existing


Table 15 Interbay bus protocols
IEC 61850-8-1
IEC 61850-8-1 interbay bus supports
- Time synchronization viaSNTP:typical accuracy ±1 ms
- Two independent time servers are supported.Server 2 as
backup time
- Optical or electrical connection
- Differential current of each protection zone
- Monitoring information from REB500 central unit and bay unit
Binary events(signals, trips and diagnostic)
-Trip reset command
- Single connection point to REB500 central unit
-Disturbance recorder access via MMS file transfer protocol
.Export of ICD - file, based on Substation Configuration
Language SCL
LON
LON interbay bus supports
- Time synchronization: typical accuracy ±1 ms
-Optical connection
-Differential currents of each protection zone
-Binary events (signals, trips and diagnostic)
-Trip reset commands
-Single connection point to REB500 central unit
.Disturbance recorder data (via HMI500)
IEC 60870-5-103
IEC 60870-5-103 interbay bus sup-
- Time synchronization: typical accuracy ±5 ms
ports
- Optical or electrical connection
- Subset of binary events as specified inIEC
Private range: Support of all binary events
Generic mode: Support of all binary events
-Tripreset command
- Disturbance recording data
Address setting of station address
0...254
Sub address setting.common address
0...255(CAA)
of ADSU
CAA per bay unit freely selectable
