ABB CMA136 3DDE300416 Generator Control and Manager

Variable name Variable name, max. 16 characters
Type Data type, e.g. REAL, BOOL, UINT etc.
State CLEAN Object is correct and loaded.
DIRTY Object version in engineering station does not match object ver sion in the station.
CREATE Object not yet loaded into station.
DELETE Object deleted in project database, but still present in station.
Access READ read-only,
WRITE write-only,
READ/WRITE read and write.
Offset Memory address offset

See also Engineering Manual, System Configuration, Process Image

Processing
ON Selected program list is switched on, and with it all lower-level programs.
All function blocks with configured processing state set to ON are evaluated
with each task cycle.
ON Selected program list is switched off, and with it all lower-level programs.
Processing of all function blocks is terminated immediately.
OK OK exits the dialog box and returns to the project tree.
ON Processing of program list is switched on.
OFF Processing of program list is switched off.
6.4 State displays in the project tree
In contrast to configuration, state information is maintained on project objects during commis sioning. This state information appears after each project object in brackets (like the object types)
and reflects the state of the process station. If arrows should appear before the nodes, these
project objects must first be loaded or reloaded into the station because of a configuration
change. An exclamation mark indicates that other objects at levels below the one so marked need
to be updated because of changes in their configuration


The color of the node in the display provides information about the effects of its configuration
change on other objects. Higher-level information may also need to be updated in the station.
In commissioning, nodes are displayed in the same formats as in configuration.
See Engineering Manual, System Configuration, Project Tree, Display of project object
states. The following details may appear after the object name and type. All states except Running are displayed in red.
6.4.1 Resource state displays
No
connection The system bus connection has been interrupted, or initialize all is currently being executed, or no connection is possible, e.g. because of an invalid network address or an incorrect station number.
Any interruption in the system bus connection will be signaled after
approx. 15 seconds.
No operating
system Seen when system is first switched on, or after initialize all of resource. No
operating system means that the operating system is loaded but is not yet
being executed. In the FieldController the operating system is loaded when
the Boot-EPROM is bootstrapped.
The FieldController holds the operating system in the Flash memory and in contrast to a rack-based redundant process station
does not require automatic operating system adjustment, as the
operating system cannot be deleted. In the case of redundancy
however the operating system version must match for both AC
800, otherwise sync status is not possible.
Stopping Resource in transition from Running to stopped.
This state is only displayed if task processing takes a relatively
long time.
Stopped [HW] Resource has been Stopped by utilizing the RUN/STOP switch on the
FieldController
Stopped [SW] Resource → Stop was selected in commissioning
