ABB DSDP170 pulse input/output unit

The drive presented in this manual is part of an

industrial environment where voltages are present

that contain a potential hazard of electric shock

and / or burn. For this reason, only personnel who

have a thorough knowledge of the drive and the

industrial environment and have obtained the

required qualification must handle, install, operate,

or maintain the drive.

The manual addresses personnel who are responsible for unpacking, transportation, installation,

operation and maintenance of the drive. The personnel must carry out the below listed tasks in a

manner that does not cause physical harm or danger, and that ensures the safe and reliable functioning of the drive.

—

Commissioning of the drive must

only be performed by qualified

and certified ABB personnel.

Handling

The personnel must be skilled and experienced in

unpacking and transporting heavy equipment.

Mechanical installation

The personnel must be qualified to prepare the

installation site according to the site and equipment requirements and to perform the installation

accordingly.

Electrical installation

The personnel must have a sound knowledge of the

relevant electrical codes and specifications covering low and medium voltage equipment, be experienced with electrical wiring principles, and know

the electrical symbols typically used in wiring diagrams.

Operation

The personnel include all persons who operate the

drive from the local operating panel of the drive.

The personnel must know the functions of the

operating panel, be adequately trained for the

drive, and know the driven process. Special knowledge of frequency converter technology is not

required.

Maintenance

The personnel include all persons who:

• are qualified to carry out preventive and corrective maintenance on drive as described in this

manual,

• are thoroughly familiar with the drive,

• have a sound knowledge of the relevant electrical codes and specifications covering low and

medium voltage equipment,

• are able to assess the hazards associated with

the energy sources of the drive system and act

correspondingly,

• know the safe shutdown and grounding procedures for the drive system.

Responsibilities of the user

It is the responsibility of those in charge of the

drive to ensure that each person involved in the

installation, operation or maintenance of the drive

has received the appropriate training and has thoroughly read and clearly understood the instructions in this manual and the relevant safety

instructions

Intended use of equipment

Those in charge of the drive must ensure that the

drive is only used as specified in the contractual

documents, operated under the conditions stipu lated in the technical specifications and on the rat ing plate of the drive, and serviced in the intervals

as specified by ABB.

Use of the drive outside the scope of the specifica tions is not permitted.

Intended equipment use also implies that only

spare parts recommended and approved by

ABB must be used.

Unauthorized modifications and constructional

changes of the drive are not permitted.

Quality certificates and applicable standards

The following certificates and conformity declara tions are available with ABB:

• ISO 9001 / ISO 14001 certificates stating that

ABB Group has implemented and maintains

a management system that fulfills the require ments of the normative standards

• EC conformity declaration

• List of the standards the drive complies with.
