GE IC697MDL350 120 VAC Output, 0.5 Amp (32 Points)
Ordering OptionsMay 8, 2002 800-003122-000 H ABC – D E F
VMIVME-3122 – –
A = Input Filter Option
0 = No Filter
1 = 10 Hz (-3 dB)
2 = 50 Hz (-3 dB)
3 = 100 Hz (-3 dB)
4 = 500 Hz (-3 dB)
B = Number of Channel Option
0 = 64 Channels High Performance
1 = 32 Channels High Performance
2 = 16 Channels High Performance
3 = 64 Channels Standard Performance
4 = 32 Channels Standard Performance
5 = 16 Channels Standard Performance
C = Input Option
0 = Differential Analog Input Channels with 96-pin Nonlatching** Connector
1 = Single-Ended Analog Input Channels with 96-pin Nonlatching**
Connector
2 = Differential Analog Input Channels with 64-pin Latching Connector
3 = Single-Ended Analog Input Channels with 64-pin Latching Connector
Connector Data
Style Recommended
Connecting Component
P3 and P4
I/O Connectors
64-pin
IDC
Mating Connector (64-pin) Panduit 120-964-435
Strain Relief (For 64-pin Connectors) Panduit 100-000-072
96-pin
Discrete
Wire
Mating Connector (96-pin Discrete) AMP 925486-1
Female Crimp Contacts
(96-pin Discrete)
AMP 530151-6*
Connector Housing
(For 96-pin Connectors)
Harting 09 03 096 0501
96-pin
IDC
Mating Connector
(96-pin Mass-Terminated)
ERNI 913.031
0.033-inch Ribbon Cable
(96-pin Mass-Terminated)
ERNI 913.049
Strain Relief Insert (0.033-inch
Ribbon Cable)
Harting 09 02 000 9912
Connector Housing (For 96-pin
Connectors)
Harting 09 03 096 0501
PC Board I/O Connector Part Number Panduit 101-096-033A
Panduit is also known as ITW/Pancon.
Notes
*AMP crimp tool part number 90301-2.
** Latches are located on the cable.
For Ordering Information, Call:
1-800-322-3616 or 1-256-880-0444 • FAX (256) 882-0859
E-mail: info@vmic.com Web Address: www.vmic.com
Copyright © November 1992 by VMIC
Specifications subject to change without notice.
Synchronization: A single scan or burst can be
initiated by an external TTL trigger through the P2
connector (External Trigger), or locally through the
CSR (Software Trigger). Either event generates a P2
Trigger output, which can be used to synchronize up to
15 boards.
VMEbus Access: Response to address modifiers is
jumper selectable as:
A32, A24, or A16 address space
Supervisory or user privilege, or both

VMEbus Compliance: This product complies with
VMEbus Specification ANSI/IEEE STD 1014-1987
IEC 821 and 297 with the following mnemonics:
A32/A24/A16:D16/D8 (EO) DTB Slave
Interrupter I(1 to 7) ROAK (DYN)
Interrupter Vector: D08 (O) (DYN)
6U form factor
VMEbus Interrupt: An interrupt request can be
generated at the end or middle of a buffer scan. The
request can also be initiated after a specific number of
samples (1 to 65,535) have been acquired. Response
vectors are controlled through Interrupt Vector
Registers.
Data Ready Flag: A data ready flag in the CSR is set
when the data buffer is filled (endscan) or half-filled
(midscan).
Interval Timer: Timed intervals of up to 687 seconds
are provided by a programmable interval timer.
Reset Operations: Board reset occurs in response to
a system reset or by writing to the Software Reset
Address. For programming-free initial operation, a
reset operation automatically establishes the following
default conditions:
Autoscanning Mode
64-, 32-, or 16-channel block size, depending on
option selected
64-, 32-, or 16-channel data buffer, depending on
option selected
Channel Gain = x1
Rate = 100 kHz conversion*
The ADC will go through a calibration cycle on either
RESET condition. The calibration cycle takes 41 ms
after a RESET operation has been initiated.
PGA: Channel gains of x1 and x10 are selected through
a Programmable Gain Amplifier (PGA). PGA gain can
be software configured for a single gain on all channels,
or it can be controlled in real-time with unique gains
assigned for each channel.
Panel Indicator: Program-controlled front panel LED
is energized during reset, and is extinguished through
the CSR.
