A = Input Filter Option0 = No Filter
1 = 10 Hz (-3 dB)
2 = 50 Hz (-3 dB)
3 = 100 Hz (-3 dB)
4 = 500 Hz (-3 dB)
B = Number of Channel Option
0 = 64 Channels High Performance
1 = 32 Channels High Performance
2 = 16 Channels High Performance
3 = 64 Channels Standard Performance
4 = 32 Channels Standard Performance
5 = 16 Channels Standard Performance
C = Input Option
0 = Differential Analog Input Channels with 96-pin Nonlatching** Connector
1 = Single-Ended Analog Input Channels with 96-pin Nonlatching**
Connector
2 = Differential Analog Input Channels with 64-pin Latching Connector
3 = Single-Ended Analog Input Channels with 64-pin Latching Connector
Connector Data
Style Recommended
Connecting Component
P3 and P4
I/O Connectors
64-pin
IDC
Mating Connector (64-pin) Panduit 120-964-435
Strain Relief (For 64-pin Connectors) Panduit 100-000-072
96-pin
Discrete
Wire
Mating Connector (96-pin Discrete) AMP 925486-1
Female Crimp Contacts
(96-pin Discrete)
AMP 530151-6*
Connector Housing
(For 96-pin Connectors)
Harting 09 03 096 0501
96-pin
IDC
Mating Connector
(96-pin Mass-Terminated)
ERNI 913.031
0.033-inch Ribbon Cable
(96-pin Mass-Terminated)
ERNI 913.049
Strain Relief Insert (0.033-inch
Ribbon Cable)
Harting 09 02 000 9912
Connector Housing (For 96-pin
Connectors)
Harting 09 03 096 0501
PC Board I/O Connector Part Number Panduit 101-096-033A
Panduit is also known as ITW/Pancon.
Notes
*AMP crimp tool part number 90301-2.
** Latches are located on the cable.
For Ordering Information, Call:
1-800-322-3616 or 1-256-880-0444 • FAX (256) 882-0859
E-mail: info@vmic.com Web Address: www.vmic.com
Copyright © November 1992 by VMIC
Specifications subject to change without notice.
Synchronization: A single scan or burst can be
initiated by an external TTL trigger through the P2
connector (External Trigger), or locally through the
CSR (Software Trigger). Either event generates a P2
Trigger output, which can be used to synchronize up to
15 boards.
VMEbus Access: Response to address modifiers is
jumper selectable as:
A32, A24, or A16 address space
Supervisory or user privilege, or both

VMEbus Compliance: This product complies with
VMEbus Specification ANSI/IEEE STD 1014-1987
IEC 821 and 297 with the following mnemonics:
A32/A24/A16:D16/D8 (EO) DTB Slave
Interrupter I(1 to 7) ROAK (DYN)
Interrupter Vector: D08 (O) (DYN)
6U form factor
VMEbus Interrupt: An interrupt request can be
generated at the end or middle of a buffer scan. The
request can also be initiated after a specific number of
samples (1 to 65,535) have been acquired. Response
vectors are controlled through Interrupt Vector
Registers.
Data Ready Flag: A data ready flag in the CSR is set
when the data buffer is filled (endscan) or half-filled
(midscan).
Interval Timer: Timed intervals of up to 687 seconds
are provided by a programmable interval timer.
Reset Operations: Board reset occurs in response to
a system reset or by writing to the Software Reset
Address. For programming-free initial operation, a
reset operation automatically establishes the following
default conditions:
Autoscanning Mode
64-, 32-, or 16-channel block size, depending on
option selected
64-, 32-, or 16-channel data buffer, depending on
option selected
Channel Gain = x1
Rate = 100 kHz conversion*
The ADC will go through a calibration cycle on either
RESET condition. The calibration cycle takes 41 ms
after a RESET operation has been initiated.
PGA: Channel gains of x1 and x10 are selected through
a Programmable Gain Amplifier (PGA). PGA gain can
be software configured for a single gain on all channels,
or it can be controlled in real-time with unique gains
assigned for each channel.
Panel Indicator: Program-controlled front panel LED
is energized during reset, and is extinguished through
the CSR.
* The standard performance option can sample at 100 kSPS, but
may not convert accurately at rates above 50 kSPS. For the
standard performance options, the user must set the sample rate
to 50 kSPS or less after reset.
