GE IC697VAL324 Analog Output, Isolated, 4channel

From: | Author:Wang | Time :2024-12-26 | 88 visit: | Share:

IEEE 802.3 Media

The Ethernet Interface (Type 2) can operate directly on

10BaseT or 10Base2 media via its 10baseT and 10Base2

network ports. These media are described below.

Additionally, the Ethernet Interface (Type 2) can

operate on any of the media listed below with the

appropriate user-supplied transceiver and transceiver

cable via its AUI network port.

10Base5 Coax: 10Base5 uses a 0.4 inch diameter 50-ohm

coaxial cable. The maximum length of a cable segment

(single span of cable) is 500 meters. The distance

between any two stations must be a multiple of 2.5

meters. A maximum of 100 stations is allowed on a

thickwire Ethernet segment.

10Base2 Coax: 10Base2 uses a 0.2 inch diameter 50-ohm

coaxial cable. The maximum length of a ThinWire cable

segment is 185 meters. A maximum of 30 stations is

allowed on a ThinWire Ethernet segment.

10BaseT: 10BaseT uses a twisted pair cable of up to 100

meters in length between each node and a hub or

repeater. Typical hubs or repeaters support 6 to 12

nodes connected in a star wiring topology.

10BaseF: 10BaseF has two variations that both use the

same type of fiber optic cable: 10BaseFP can support up

to 33 nodes at distances of up to 500 meters from a

passive star; 10BaseFL supports up to 2000 meters

between a node and a repeater (a multi-port repeater

would thus constitute a star). Additionally, 10BaseFB

provides a means of interconnecting (only) repeaters by

up to 2000 meters of (the same) fiber optic cable.

Note

Various Ethernet baseband media listed above

can be interconnected by appropriate repeat ers. Capabilities and limitations are defined in

IEEE 802.3 Chapter 13, System Considerations for

Multi-Segment Networks.

10Broad36: 10Broad36 uses 75-ohm coaxial cable and

CATV-like media components (taps, amplifiers, headend

translators, etc.) to support hundreds of nodes at

distances of up to 2800 meters. Broadband cannot be

connected to baseband via repeaters. Broadband cable

plant design and installation must be in accordance with

IEEE 802.7 and requires special expertise. GE Fanuc

recommends you contract professional specialists for

these services. Consult your local authorized GE Fanuc

PLC distributor, or your GE Fanuc sales representative

or field service office for help in identifying local

specialists.
