GE IS215AEPCH2F AEPC - 30Nm Non-CANBus Air Distance Control (Center/Axle)

From: | Author:Wang | Time :2024-12-18 | 100 visit: | Share:

GE IS215AEPCH2F AEPC - 30Nm Non-CANBus Air Distance Control (Center/Axle)

This appendix gives a brief description of the setup options in the system BIOS.
Due to the custom nature of GE’s SBCs, your BIOS options may vary from the
options discussed in this appendix.
AMI refers to their BIOS setup screens as ezPORT. For a complete description of
all the options available with the AMI BIOS, please visit www.ami.com and
download their ezPORT PDF file. The options listed on AMI’s web site may not be
available on your system.
To Access the First Boot pop up screen press the F11 key at the beginning of boot.
To access the ezPORT setup screens, press the DEL key at the beginning of boot.
B.1 First Boot Menu
The V7768/V7769 have a First Boot pop up menu enabling the user to, on a one time
basis, select a drive device to boot from. This feature is useful when installing from
a bootable disk. For example, when installing an operating system from a CD,
enter the First Boot menu and use the arrows keys to highlight ATAPI CD-ROM
Drive. Press ENTER to continue with system boot.
This feature is accessed by pressing the F11 key at the very beginning of the boot
cycle. The selection made from this screen applies to the current boot only, and
will not be used during the next boot-up of the system. If you have trouble
accessing this feature, disable the QuickBoot Mode in the Main BIOS setup screen.
Exit, saving changes and retry accessing the First Boot menu.


The Main BIOS setup menu screen has two main areas. The left frame displays all
the options that can be configured. “Grayed-out” options cannot be configured.
Options in blue can be configured. The right frame displays the key legend.
Above the key legend is an area reserved for a text message. When an option is
selected in the left frame, it is highlighted in white and a text message in the right
frame gives a brief description of the option.
The Main menu reports the BIOS revision, processor type and clock speed, and
allows the user to set the system’s clock and calendar. Use the left and right arrow
keys to select other screens.
Below is a sample of the Main screen. The information displayed on your screen
will reflect your actual system.
Table B-2 AMI BIOS Main Menu
002.53 (C) Copyright 1985-2002, American Megatrends, Inc.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Security Chipset Exit
System Overview Use [Enter], [TAB]
Or [SHIFT-TAB] to
Select a field.
Use [+] or [-] to
Configure system
Time.
←→ Select Screen
↑↓ Select Item
+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
AMIBIOS
Version : 08.00.10
Build Date : 03/02/04
ID : 07807_16
Processor
Type : Intel(R) Pentium (R) M processor 1600MH
Speed : 1600MHz
System Memory
Size : 1016MB
System Time [11:39:40]
System Date [Tue 03/04/2004]
