GE IS215WEPAH1A IS215WEPAH1B WEPA - 30Nm CANBus Air Distance Axle Control

The second method of selecting the Boot-from-LAN BIOS option is to press the

DEL key during system boot. This will access the BIOS Setup Utility. Select the Boot

menu, and then select the Boot Device Priority sub-menu. Use the arrow keys to

highlight the Network:IBA GE Slot option. Repeat entering <+> until the desired

network port is at the top of the list.

Advance to the Exit menu, select Exit Saving Changes and press ENTER. When the

system prompts for confirmation, press Yes. The computer will then restart the

system bootup. The system will boot from this connection until it is changed in

the BIOS Setup Utility.

Table C-3 Boot-from-LAN BIOS Boot Menu

C.3 BIOS Features Setup

After the Intel Boot Agent has been enabled, the following information will

appear at the top of the screen.

Initializing Intel (R) Boot Agent GE v1.2.40

PXE 2.1 Build 085 (WfM2.0)

Press Ctrl+S to enter Setup Menu...

Once you press CTRL-S, the Boot Agent setup menu will appear. PXE is the boot

option available on the V7768/V7769. You can change the settings for the Setup

Prompt and Setup Menu Wait Time. You can either enable or disable the prompt,

and you can set the amount of wait time for the setup menu.

Once the configuration is set, the SBC will begin to establish the new link.

Initializing Intel (R) Boot Agent GE v1.2.40

Initializing and establishing link...

BIOS SETUP UTILITY

Boot

Boot Device Priority Specifies the boot

sequence from the

available devices.

←→ Select Screen

↑↓ Select Item

+- Go to Sub Screen

F1 General Help

F10 Save and Exit

ESC Exit

1st Boot Device

2nd Boot Device

3rd Boot Device

[MBA UNDI (Bus2 Slot5)]

[1st Floppy Drive]

[Hard Drive]

Network Boot Protocol PXE (Preboot eXecution Environment)

Boot Order Use BIOS Setup Boot Order

Show Setup Prompt Enabled

Setup Menu Wait Timer 2 Seconds

The V7768/V7769 include a Boot-from-LAN BIOS option which allows the SBCs

to be booted from a network. This appendix describes the procedures to enable

this option and to select a LAN connection as the boot device.

NOTE

The options listed in this appendix may not be available on your system.

C.1 Enabling the Front Panel (FP) LAN

The LAN must be enabled in the Boot Setup Utility in order to perform a remote

boot. The board will only remotely boot from the front panel LAN connection.

The Chipset menu of the BIOS Setup Utility allows the LAN to be enabled.

Table C-1 shows the Chipset Menu. Use the arrow keys to highlight the Onboard

Devices Configuration. Select Onboard FP LAN and enter <+> until the option is set

to Enabled. Press F10 to Save and Exit the BIOS Setup Utility. This will allow the

LAN to be a boot device.

Table C-1 Enable the Front Panel LAN for Remote Booting

BIOS SETUP UTILITY

Main Advanced PCIPnP Boot Security Chipset Exit

Advanced Chipset Settings Intel Montara GML

NorthBridge chipset

Configuration options.

←→ Select Screen

↑↓ Select Item

Enter Go to Sub Screen

F1 General Help

F10 Save and Exit

ESC Exit

WARNING: Setting wrong values in below section

may cause system to malfunction.

¾ NorthBridge Configuration

¾ SouthBridge Configuration

¾ Onboard Devices Configuration
