Woodward Industrial Turbine Products

From: | Author:Wang | Time :2025-06-13 | 83 visit: | Share:

Woodward Industrial Turbine Products

Turbine control and related equipment

2301E-ST steam turbine control: There are two types: normal position and hazardous zone 2, with part numbers 8273-1013 and 8273-1014, respectively. The document refers to product specification 03407 and manual 26694.

Turbine control: 2301E-HT model is suitable for Francis turbine, 24VDC, normal position, part number 8237-2046, document reference product specification 03459 and manual 35092.

Peak200 steam turbine control: There are multiple installation methods and voltage specifications, such as LV type part number 8200-1500 for cabin wall installation, HV type part number 8200-1501 for front installation, etc. Refer to product specification 03438 and manual 35051 for documentation.

505 steam turbine control: including different voltage and position types, such as LVDC common position part number 8200-1300, HVAC/DC common position part number 8200-1301, etc., as well as 505-XT and 505-DR series. Refer to product specification 03422 and relevant manuals for documentation.

5009XT Steam Turbine Control: Depending on the power supply, there are three types: 2120V AC/DC, 220VAC, and 24VDC, with part numbers 8262-1141, 8262-1142, and 8262-1143. Accessories include a touch screen and software license.

Servo position controller: can replace digital remote final drives, such as the configurable servo/actuator drive part number 8200-226 certified for marine use, and part number 8200-227 with CANOpen communication.

ProTech overspeed protection device: including ProTech SX, ProTech GII, ProTech TPS, MicroNet safety module, etc., with different installation methods and relay configurations, part numbers such as ProTech SX panel installation HV/LV type 8237-1242, ProTech GII cabin wall installation HV/LV independent relay type 8237-2594, and conversion kit.


Compressor control and related equipment

Vertex controllers: available in different voltage and compliance types, such as compressor control part numbers 8200-1370 for 18-36VDC standard compliance, 8200-1371 for 88-264VAC or 90-150VDC standard compliance, etc. Accessories include distributed I/O modules and remote viewing software licenses.

Electronic control

2300E electronic load sharing and speed control: available in hardware only version, with part numbers 8273-1017 for regular location and 8273-1018 for hazardous area 2. Refer to product specification 03405 and manual 26691 for documentation.

Flex500 platform: There are different installation methods and voltage types, such as front mounted LVDC with OCP part number 8200-1343, back mounted HVAC/DC part number 8200-1354, etc. Accessories include core source license and communication module.

MicroNet system modules, cables, and accessories:

Chassis: such as 8-slot MicroNet Plus chassis part number 5453-829, TMR chassis part number 5453-279.

Power supply: including MicroNet Plus power supply with 24VDC, 110VAC/125VDC, 220VAC input, and TMR power supply.

CPU modules: such as 5200CPU MicroNet TMR part numbers 5466-1347 and 5466-1247, MicroNet Plus P1020 CPU part number 5466-1511.

Communication module: such as RTN to CAN gateway part number 8200-1250, remote RTN part number 5466-1146.

Input/output module: including speed sensor, pressure interface, actuator driver, etc., such as 4-channel speed sensor part number 5466-5000, 2-channel actuator driver part number 5501-1428.

LINKnet HT and RTCnet modules: For example, RTD inputs 8-channel part numbers 8200-1200 and 8200-1100, and thermocouple inputs 8-channel part numbers 8200-1201 and 8200-1101.

Dataforth I/O: including K-type thermocouple, 100 Ω RTD, 4-20mA input, and 0-5VDC input module, part numbers such as 1784-1028, 1784-655, etc.

Network switch: 8-port Ethernet switch part number 1711-1350.

Cables: including NetCon analog and discrete cables, Ethernet Cat-5 cables, MicroNet TMR cables, etc., such as 6-foot NetCon analog cable part number 5416-346, 3-foot NetCon discrete cable part number 5416-332.

MicroNet TMR and Plus hardware kits: such as TMR hardware kits with 4565-1115 part numbers 8262-1145 to 8262-1150, standard MicroNet+kit part numbers 8262-3183, etc.

Magnetic pickups and active proximity probes: Magnetic pickups have different threads, lengths, and resistances, such as MPU-70 VPP part number 202816, MPU-50 VPP part number 1680-613; Active proximity probes such as 5-24VDC part number 1680-986 and 7-30VDC part number 1689-1114.

Software License

GAP software program: GAP-Reader does not require a license, Monitor GAP license part number 8928-5007, Editor GAP 4. X license part number 8928-5359.

The latest ITCC software core includes ASC1 to ASC4 anti surge control, STC steam turbine core, etc., with part numbers such as 5418-3675 to 5418-3678, 10-027-206, etc.

GUI development and viewing program licenses: CIS annual subscription license part number 1796-3131, RemoteView license part number 8928-5311, iFix HMI software licenses such as 1796-3132 and 1796-3145.

Software service tool programs and suites: Control Assistant license part number 8928-5014, ToolKit developer license part number 8928-5016, AppManager data log retrieval enterprise license part number 8928-5009.

NetSim simulation license: NetSim nVe Nodes Only license part number 8928-5363, Advanced license part number 8928-5364, and annual subscription license.

Remote access program: Site Manager Module part number 1711-1418, LinkManager license part number 8928-5347, GateManager setup and support fees.


Electro hydraulic governor and actuator

TG turbine governor: such as TG13 and TG17 series, with different speeds, rotation directions, and droop rates, part numbers such as TG13 screw 2400rpm CCW rotation ATEX part number 9904-814, TG17 screw 2400rpm CCW rotation ATEX part number 9904-800.

TG611: Includes conversion kit and different specifications of speed controllers, such as TG611-13 screw 2400rpm CCW with OTD part number 8516-175.

TGE turbine actuator: There are 2400rpm, 4000rpm, 6000rpm according to different speeds, with part numbers such as TGE13 2400rpm part number 9904-110.

VariStroke actuator: It needs to be selected according to the model number, with double acting and single acting options. The part number is V45TD-2015-FUXM-X-S-X, part number 9907-1338, as well as VS-I, GI, DX servo and spare parts kit.

UG25+steam turbine governor and actuator: governor part numbers such as 8528-122 to 8528-137, actuator part numbers such as 8528-027 to 8528-327.

UG actuators: such as UG2 MPU CW dual lip drive seal part number 8251-212, UG15 series part number 8251-719, etc.

CPC-II current pressure converter: available in different pressure and area levels, such as 10Bar Class1 Div2 part number 9907-1200, 25Bar Class1 Div1 part number 9907-1197, and CPC-DX redundant kit.

TM linear actuator: such as TM-25LP single coil extension part number 9907-1213, TM-200LP single coil retraction part number 9907-1225.

Turbine shutdown trip block components: The QuickTrip series is SIL-3 certified, with part numbers 0-9907-2108 for regular positions and 1-9907-2108 for Zone 1&2 positions. Spare parts include specialized tool kits and solenoid valve replacement kits.


Gas turbine valve

GS40 and GS50 gas fuel valve actuators: with onboard drivers, GS40 comes in 1.5-inch RF600 # and SAE specifications, part numbers such as 9908-1608 to 9908-1654; GS50 comes in 2-inch RF600 # and SAE specifications, with part numbers such as 9908-1605 to 9908-1673.

LQ6 liquid fuel valve actuator: The part numbers are 9908-1519, 9908-1520, and 9908-271 depending on the port size.

LQ25 standard valve: such as 0.1 square inch with PIV and SOV part number 9908-238, 0.2 square inch part number 9907-696, 0.3 square inch part number 9907-996.

LSOV25 liquid fuel shut-off valve: available in 24VDC and 125VDC, with proximity switch, part numbers such as 9908-359, 9908-358, 9908-363, 9908-361.

USOV universal shut-off valve: 2-inch 900 #, 1.6ACD, 24VDC part number 9907-1233.

GSOV80 and GSOV25HT gas fuel shut-off valves: GSOV80 is 3-inch HP, 24VDC and 125VDC, part numbers 9907-2328, 9907-2335; GSOV25HT has 24VDC and 125VDC, with on/off position switch, part numbers such as 9907-861 to 9907-899.

DVP digital valve positioner: available in 24VDC and 125VDC, with different protection levels and output powers, such as 24VDC IP30 TB input/output part number 8200-507, high output 5KW part number 8200-538, 10KW part number 8200-536, 12KW part number 8200-556.


L series actuators and integrated speed control

L series speed control - actuator only: part number 8404-7101, similar to 8404-536 and 8404-1001.

L series speed control - with ITB actuator: Depending on the ITB size, such as 36mm part numbers 8404-2007 and 8404-7, 43mm part numbers 8404-2008 and 8404-7, 50mm part numbers 8404-2009 and 8404-2033.

L series process control - with ITB: including air-fuel ratio control, such as 16mm trim valve part numbers 8404-3001 and 8404-7301, 22mm part numbers 8404-3002 and 8404-7302, and sealed ITB such as 25mm part numbers 8404-2035 and 8404-2061.

L series speed control - with ITB and Venturi mixer (MAS): such as LC50 25mm ITB part number 8404-4001, 30mm ITB part numbers 8404-4002 to 8404-4009 and 8404-7405 to 8404-7409.

L series diesel actuator applications: such as Stanadyne cover/shaft speed control part numbers 8404-563 and 8404-7503, Delphi cover/shaft with lever part numbers 8404-5004 and 8404-7504.

L series with ITB locator: such as 16mm fine adjustment valve part numbers 8404-3003 and 8404-7303, 22mm part numbers 8404-3004 and 8404-7304, sealed ITB such as 25mm part numbers 8404-2013 and 8404-7213.

L series accessories: including gaskets, HEGO sensors, cables, and communication interface kits, such as 16&22mm gasket part number 3051-073, HEGO sensor part number 1680-6005.

F-series actuators and actuators with ITB

F-series locator: There are different ITB sizes and installation methods, such as 33mm ITB standard installation 23 pin part number 8245-027, 48mm ITB standard installation 23 pin part number 8245-052, 60mm ITB standard installation 23 pin part number 8245-003, 68mm ITB standard installation 23 pin part number 8245-004. Accessories include 14 pin and 23 pin mating connector kits.


R series actuators

R-series actuators: R-11, R-30, R-120 electric positioners, R-11 is suitable for fuel racks, part number R11 positioners are not preferred 8410-001, replace 8410-007; R30 locator replacement 8410-008; R120 locator 8410-010.


ProAct actuator

ProAct 75 Speed Control (First Generation): Old part number such as 8400-010, new part number 8400-059, including driver and ITB, such as driver part number 8400-706, ITB part number 8235-399.

ProAct locator (16 pin, third-generation): Model II part number 8404-302, Model III part number 8404-303, Model IV part number 8404-304.

ProAct locator (Flex I/O): such as GEN3 FLEX Model II part numbers 8404-307, 8404-317, 8404-319, Model III part numbers 8404-308, 8404-318, Model IV part numbers 8404-309, 8404-315, etc.

ProAct ITB (3rd generation): 105mm ITB part number 8335-003120mm ITB part number 8335-004135mm ITB part number 8335-005.


TecJet fuel control valve

TecJet fuel control valve: suitable for different systems, such as TecJet 52 part number 8407-605 for EGS-01, part number 8407-603 for EGS-02/E6, Jenbacher specific part number 8407-636, CAT specific part number 525-8021, as well as TecJet 85 and 110 series.
