ABB KX8974c V24 HIEE320606R1 Power Module

xcitation systems are typically

used in power-plants for generator

control. This is an application in

which reliability is the most important

requirement. As opposed to the previous example, these systems can be

very large and incorporate several

subsystems.

In this case, the introduction of the

PP D104 permitted the division of the

entire system into several independent

sub-systems, each dedicated to a particular subset of tasks, and with each

subsystem being controlled by a separate controller. The total system is

then controlled and coordinated by a

powerful main controller based on the

PP D103 processor module.

This modularization not only greatly

reduced the complexity of the overall

system, but presents two further

main advantages: scalability and reliability.

Traditionally, systems that are scalable

over a very broad range of sizes come

at the cost of a complex architecture

and hence impose difficulties for the

engineering staff. The modularization

made possible by the low-end extension of AC 800PEC allows the implementation of a very natural scalability

over a broad range. Each sub-system

can be instantiated several times without further complicating the software

in the main controller.

As already mentioned, reliability of

the system is a key issue in powergeneration, and often full redundancy

is required. Whereas in slower systems, the controllers themselves can

be realized as redundant devices, the

cycle-times found in and required by

power electronic systems make traditional redundancy concepts for controllers unworkable.

Here, the solution of choice to

achieve redundancy is no longer on a

device level, but on a system level.

For the redundancy concept implemented in ABB’s UNITROL® excitation

systems, each subsystem is available

n-times. In case of a problem in one

subsystem, the main controller switch es over to the remaining subsystems,

which are scaled in such a way that

the overall task can still be fulfilled 4 .

Should the main controller fail, there

is always a second controller available

in hot-standby.

n 2002, ABB introduced its high-end

control platform, AC 800PEC, to

target the important field of high-per formance control.

The market required a combination of

several features:

High processing power

Short cycle-time (<100 µs)

Fast time-to-market for applications

Suitable for small series

Industrial grade hardware

High integration of devices
