ABB NAIO-03 64212389 Inverter I/O Expansion Unit

From: | Author:Wang | Time :2024-12-10 | 98 visit: | Share:

For communication gateways,minimal engineering

and implementation of standard and non standard

protocols is crucial. The RTU560 with its open

architecture and user friendly tools satisfies these

requirements.

Application Station Automation

Benefits:

• Cost optimized station automation with

IEC 60870-5-103

• Data engineering for RTU and HMI

in one step

• Use of the RTU560 communication network

for disturbance data and load profiles

• Retrofit with digital bay controllers possible

step by step

Benefits:

• Reduction of complex front-end systems

• Higher availability of WAN networks

• Reduced costs for data engineering

• Redundancy concept adaptable to

availability requirements

Station Automation

The station automation application consists of

interfaces to a mixture of protection and control

equipment as well as metering devices and other

automation products.The Human Machine Interface integrated into the RTU560 allows a basic local

control and monitoring.

Transmission of disturbance records and load profiles by using the communication network of the

RTU560 are also available functions

The software and hardware concept is based on

modularity. The software application tasks can be

organized in such a way as to be distributed over

different communication units (CMU boards).

This is possible due to an internal communication

concept that keeps all CMU boards informed about

the contents of the process data interface. There is

one process and system database which is available

in adapted copies for each CMU board.

The internal communication system ensures that

all process data are consistent. The different CMU

boards run the communication tasks for the

connected serial links. This allows the type and

number of different communication links running

on one CMU board to be defined.System perfor mance is defined by the configuration of the CMU

boards.
