ABB NTAC-02 3BHL000511P0003 Pulse encoder

From: | Author:Wang | Time :2024-12-10 | 128 visit: | Share:

The data engineering of the RTU560 can easily

be carried out by the user with the help of the

MS-WindowsTM based tool RTUtil 560 and by MSExcelTM signal lists.

RTUtil 560 is designed to engineer small RTU560,

medium-sized RTU560 with a set of included IEDs,

and also to engineer router RTUs with all the types

of communication links and IEDs used in the customer's network.Process signal mapping to the

different communication protocols is one of the

main tasks needed in hierarchical communication

network structures. The process signals of a small

RTU connected at the lowest level of a network

may be routed via other RTUs on the way up to

the final network control center (NCC). All necessary communication links and parameters are

engineered with RTUtil 560 in one project.

The signal and communication data can be entered

into RTUtil 560 via import of MS-ExcelTM signal

lists.Therefore only limited RTUtil 560 knowledge

is required. The use of MS-ExcelTM functionality

allows quick and easy data entry of large volumes

of process data.To allow adaptations to specific

customer or project requirements,the structure

of the MS-ExcelTM sheets used for data import is

expandable and can also be used for documentation.

The Engineering principle in RTUtil 560 is according to IEC 61346-1 standard.With the RTUtil 560,

separate views for signals,hardware,and communication data is possible.This makes configuration

changes easy.Before generating configuration files,

the RTUtil 560 system carries out an engineering

data consistency check. Any engineering errors

occurring will be recognized and logged in files

with the error location.

Engineering

The configuration file transfer will be done by

using the integrated web server connected to the

RTU560 MMI interface. The configuration of the

RTU560 can also be carried out from a remote

PC via Internet links or the customer's Intranet.

Download by a network control center via IEC

60870-5-101/104 file transfer protocol is also pos sible.Upload of the data files is used for reverse

data engineering.

Benefits:

• Running on standard MS-WindowsTM

Operating systems (XP,2000 and NT)

• Process data engineering with MS-ExcelTM

possible with limited RTUtil 560 knowledge

• Quick and easy engineering method for

larger projects

• Already existing MS-ExcelTM signal lists can

easily be adapted to the required format

• MS-ExcelTM templates can be used for

documentation

• Engineering and modification efforts

can be reduced considerably

• MS-ExcelTM template adaptable to customers'

requirements
