ABB REF601 BA426BA1XE feeder protection and monitoring device

From: | Author:Wang | Time :2024-12-12 | 269 visit: | 🔊 Click to read aloud ❚❚ ▶ | Share:

ABB REF601 BA426BA1XE feeder protection and monitoring device

Auxiliary voltage
Nominal voltage range 110 to 220 VAC / VDC
Permissible voltage range 85 to 265 VAC
85 to 375 VDC
Maximum power consumption 25 W / 35 VA
Measuring inputs
Nominal voltage range 50 to 130 VAC
Voltage range 0 to 110 % Un
Nominal frequency 16 2/3, 50 / 60 Hz
Frequency range 10 to 100 Hz
Inputs
Refer to SYNCHROTACT® 5
Outputs and parameter setting ranges
Isolation
Dielectric test IEC 60255-5 2 kV
Impulse voltage withstand test IEC 60255-5 5 kV
Temperature ranges
Transport/storage -25 to +65 °C
Operation -25 to +40 °C
Interference immunity/transmission (EMC)
Refer to SYNCHROTACT® 5
Environmental values
CE conformity
EMC directive 2014/30/EU
Generic standard EN 61000-6-2
EN 61000-6-4
Emission
Immunity
Low voltage directive 2014/35/EU
Safety of information technology equipment EN 60950
Product standards
Measuring relays and protection equipment IEC 60255-6
Relevant standards
Protection type according to IEC 60529
Front IP 50
Rear IP 00
Dimensions
width x height x depth 482 x 399 x 297 mm
Weight
Depending on the version 15 to 16 kg


The system uses proven SYNCHROTACT® 5-components
and may be individually adapted. Typical configurations are as
follows:
1. Safety: Single- or dual-channel solutions
2. Availability: Redundant manual synchronizing or redundant
automatic synchronizing or both
3. Number of circuit breakers to be synchronized: up to four circuit
breakers, one or more of which may be generator breakers
4. Power supply: In case of redundant synchronizing, the
power supply on the cubicle entrance can be redundant too.
5. Synchronizing control: Remote, local or both
6. Adaptation of the measuring voltages: Especially with
synchronizing of several circuit breakers it may occur that the
two secondary voltages have different amplitudes and
phase angles with closed circuit breaker.
Examples of synchronizing concepts
Automatic synchronizing (sketch shows dual channel version)
including separate synchrocheck for redundant manual
synchronizing (with its own hardware and power supply).
Redundant, automatic dual channel synchronizing with
the additional possibility of a manual synchronizing (using
parameter set 7).
