ABB SPASO11 RTD analog output module

From: | Author:Wang | Time :2024-12-16 | 103 visit: | Share:

ABB SPASO11 RTD analog output module

The optional Control Panel offers a
user-friendly means to
communicate with the drive.
• Different languages defined by application
program
• 2×20 character display
• Simple operation with 10 pushbuttons (mem brane panel well suited to industrial environ ments)
• Common for AC and DC drives
• Door mounted
The Control Panel provides the following infor mation and functions:
• Status information (run, ready, fault messages)
• Operational control with 4 freely programma ble pushbuttons
• Display of reference values (speed, torque)
• Display of actual values (speed, voltage, cur rent)
• Display of fault logger contents
• Uploading, downloading, changing, displaying
and saving the Application Controller APC and
Drive Controller DDC parameters.
Commissioning, maintenance and programming is easy
with the dedicated Windows™ based PC programs.
Digital-Drive-Control-Tool
(DDCTool) for Commissioning and
Maintenance
DDCTool is ABB’s new PC program, common for
both AC and DC drives.
• Runs under Microsoft® Windows™
• Intuitive, easy-to use
• Graphical User Interface
• Fast response
The DDCTool offers the following functions:
• Monitoring of reference and actual values
• Setting, changing, saving, uploading,
downloading, and restoring of parameters
• Controlling and displaying data loggers
• Display and clear of the fault logger
• Selection of target drives in multi-drive
applications
Engineering Tool for Individual
Programming
The application controller (APC2) is a program mable controller by using Adva Build for Win dows (FCB)


DCV 700 can be tailored to meet different
needs by using a combination of the
following options.
• Regenerative Stop
This type of emergency stop provides fast stop, stop by ramp,
coast stop and dynamic braking. An external push-button is
connected to a digital input and when activated it will force the
drive, with regenerative braking (fast stop), to stop and then
open the main contactor.
This function works with a hardware safety function that
insulates the motor from the network if there is a failure in the
drive.
• Electrical Disconnect (Coast Stop)
The electrical disconnect function opens all the main contactors in the converter, allowing the drive to coast stop.
A pushbutton is connected to a digital input which will give the
order to the software to open the main contactor. This function
also includes a hardware safety function similar as for the
emergency stop.
• Auto Reclosing
If the AC mains supply is lost for a short time, the drive will
restart automatically. Technical data has to be specified in each
case.
• Earth Fault Protection (current sensitive)
Earth fault protection includes a zero measuring current
transformer and operates on the current summation principle.
In a direct earthed supply this protection will detect the first
earth fault and will disconnect the converter.
In an impedance earthed or an isolated system this protection
will detect the second earth fault provided that it is on opposite
sides of the current transformer.
• Insulation Monitor (voltage sensitive)
An insulation monitor for single drives or for system drives
can be provided for the detection of ground faults.
The insulation resistance is constantly monitored for the
system, and earth faults are detected for both AC and DC
circuits.
• Motor Starter
A motor starter can be provided for overload and short-circuit
protection of an external AC motor such as a motor cooling fan.
The AC voltage is the same as the drive´s supply voltage. The
following ratings are available: 400...690 V, 0.63 A...25 A
• Galvanic Isolation
Galvanic isolation is used for measuring of AC- and DC-voltage
with a transformer and a galvanic isolated transducer. This
option is recommended for supply voltages > 690 V (available for converter ratings 855...5150 A).
• Cabinet design according to EMC-regulations
Air inlet filters welded, bottom plate with cable entry, door
