ABB HIEE300888R0002 UAC389AE02 medium and high voltage inverter control motherboard

From: | Author:Wang | Time :2024-12-05 | 90 visit: | Share:

ABB HIEE300888R0002 UAC389AE02 medium and high voltage inverter control motherboard

NOTE! During any local man-machine communication over the push buttons and the display on the front panel a five minute time-out
function is active. Thus, if no push button has
been pressed during the last five minutes, the
relay returns to its normal state automatically.
This means that the display turns dark, the relay
escapes from a display mode, a programming
routine or any routine going on, when the relay
is left untouched. This is a convenient way out
of any situation when the user does not know
what to do.
Before a relay module is inserted into the relay
case, one must assure that the module has been
given the correct settings. If there however is
any doubt about the settings of the module to be
inserted, the setting values should be read using
a spare relay unit or with the relay trip circuits
disconnected. If this cannot be done the relay
can be sett into a non-tripping mode by pressing
the PROGRAM push button and powering up
the relay module simultaneously. The display
will show three dashes "- - -" to indicate the nontripping mode. The serial communication is
operative and all main and submenues are accessible. In the non-tripping mode unnecessary
trippings are avoided and the settings can be
checked. The normal protection relay mode is
entered automatically after a timeout of five
minutes or ten seconds after the dark display

position of the main menu has been entered.

Fig. 4.Example of part of the main and submenus for the settings of the overcurrent and earth-fault

relay module SPCJ 4D29. The settings currently in use are in the main manu and they are displayed
by pressing the STEP push button. The main menu also includes the measured current values, the
registers 1...9, 0 and A. The main and second setting values are located in the submenus and are
called up on the display with the PROGRAM push button.
Operation in the setting mode. Manual setting
of the main setting of the start current value I>
of an overcurrent relay module. The initial valuea)
Press push button STEP repeatedly until the
LED close to the I> symbol is lit and the current
start value appears on the display.b)
Enter the submenu to get the main setting value
by pressing the PROGRAM push button more
than one second and then releasing it. The red
display digit now shows a flashing number 1,
indicating the first submenu position and the
green digits show the set value.c)
Enter the setting mode by pressing the PRO GRAM push button for five seconds until the
display starts flashing
