ABB UFC718AE01 HIEE300936R0001 programmable control module

Commanded output status from the

processors are received by an output

module which, using a 2oo3 hardware

voter, sets the outputs to the field.

Any discrepancy is detected by the

micro-controllers and reported to the

processors.

All input and output modules can be

optionally configured with a hot spare

partner module. This allows repairs to

be carried out without affecting the

operation of the system.

Triguard SC300E Chassis

System

There are four basic types of chassis, all

using the same mechanics, each

providing 10 slot positions for I/O

modules and redundant power supplies.

• The Main Chassis

One per system is required and is

always complete with two power

supply units, three processor

modules, the chassis backplane with

triple bus systems and plug/socket

system module connectors.

• An Extension Chassis

Up to 14 chassis can be connected

to a main chassis to suit the capacity

master bus extender modules. The

master chassis can service up to four

remote chassis.

• A Remote Chassis

Always equipped with two power

supply units and three fibre optic

slave bus extender modules.

A remote chassis can be sited up to

2km away from a remote master.

Processor

Each Triguard SC300E TMR system

contains three processors. Each

processor operates asynchronously in

parallel with the other two processor

modules and receives power from the

redundant power supply units in the

main chassis. A triplicated bus system

on the chassis backplane connects

Key features of the processor modules:

• Intel processor

• Battery backed static RAM for

application logic

• RAM Battery backup supply for six

months

• 1 Mbyte of EPROM

• Real time clock for data logging to

10ms resolution
