A-B Ultra3000 and Ultra5000 with DeviceNet

The Ultra3000 is an easy-to-use, high-performance, digital servo drive in a compact package.

Reduced size, high performance and low cost make the Ultra3000 an attractive solution for a wide variety of applications.

It is ideal for stepper, stand-alone indexing, or standard velocity or position control.

With DeviceNet, users can dynamically adjust and change Ultra3000 commands from a PLC or Operator Interface.

The Indexing option combined with DeviceNet allows the end user to perform complete motion profiles over DeviceNet.

DeviceNet communication also provides Ultra3000 system diagnostics at the system controller.

The Ultra5000 is tailored for high-speed motion processing, position capture, and advanced math capabilities to increase application performance.

When communicating over the DeviceNet network, the Ultra5000 user program can dynamically adjust to changing commands and parameters from a supervisory PLC or Operator Interface.

Multiple Ultra5000 Drives can be networked with a single PanelView Operator Interface for a cost-effective application solution.
