GE VMIVME-1111 64-bit High-Voltage Digital Input Board with Built-in-Test

The VMIVME-7807/VME-7807RC provide front panel access for the PMC expansion

site, an optional Gigabit Ethernet port, one 10/100 RJ45 connector, one serial port,

SVGA, keyboard/mouse, the manual reset switch and the status LEDs. A drawing of

the VMIVME-7807/VME-7807RC front panels are shown in Figure 1-5. The front

panel connectors and indicators are labeled as follows:

• 10/100 10/100 Mbit Ethernet connector

• G1 10/100/1000 Mbit Ethernet connector 1 (or LEDs) port 1

• G2 10/100/1000 Mbit Ethernet LEDs port 2

• M/K Mouse/keyboard connector

• COM1 Serial Port

• RST Manual reset switch

• S Status LEDs

• SVGA Analog Video connector

The VMIVME-7807/VME-7807RC provide rear I/O support for the following: digital

video, Serial ATA, COM2, 3 and 4, IDE drive and two USB ports. These signals are

accessed by the use of an RTM such as the VMIACC-0586/ACC-0586RC and the

VMIACC-0590/ACC-0590RC, which terminates into industry standard connectors.

The front panel connectors, including connector pinouts and orientation, for the

VMIVME-7807/VME-7807RC are defined in Appendix A. Rear panel connections are

defined in the appropiate RTM Installation Guide. Contact Sales for compatible RTMs

offered by GE Fanuc Embedded Systems.

Status LEDs (from left to right)

Sysfail VME failure- Lights during

VME SYSFAIL condition,

(Red LED).

PWR Power - Indicates when

power is applied to the

board, (Green LED).

IDE Activity Indicator - Flashes

when IDE activity is

occurring, (Yellow LED).

Boot Done Booting - Indicates BIOS Boot

is in progress. When LED is

off, CPU has finished POST

and is ready, (Red LED).

RST Switch Reset - Allows the system to

be reset from the front panel.

10/100 Ethernet LEDs

Link Indicates the Ethernet is

active, (Green LED).

Activity Indicates whether 10BaseT

(Yellow LED) or 100BaseTX

Green LED) mode is active.

Front Gigait Ethernet LEDs

Link Indicates the Ethernet is

active, (Yellow LED).

Activity Indicates whether

10BaseT (LED Off),

100BaseTX (Yellow LED) or

1000BaseT (Green LED)

Ethernet mode is active.

Rear Gigait Ethernet LEDs

Link Indicates the Ethernet is

active, (Green LED).

Activity Indicates whether

10BaseT (LED Off),

100BaseTX (Yellow LED) or

1000BaseT (Green LED)

Ethernet mode is active.
