GE VMIVME-4132-010 32-Channel, 12-bit Analog Output Board with Built-In-Test

From: | Author:Wang | Time :2024-12-17 | 311 visit: | 🔊 Click to read aloud ❚❚ ▶ | Share:

GE VMIVME-4132-010 32-Channel, 12-bit Analog Output Board with Built-In-Test

Legend: Setup>Config Subtab Example
ID Description
1 Function Select list: List of all objects in the analyzer
2 Object Configuration Information: Displays all information available for the selected list item
including Action Icons (if applicable) and Fields. Editable fields display with a white
background.
3 Subtabs: Switch views by selecting the desired tab.
4.6.1 File management
The File Management button in the Function Select list allows the user to delete files from the analyzer
libraries, restore the analyzer to factory configuration, create a user restore point, restore the
analyzer to the user-created restore point, backup the analyzer to a USB drive, backup all stream files
to a USB drive and delete all stream files on the SBC.
To delete files from the Analysis Configuration or system Libraries:
1. Press the Abort button to open a window displaying the system libraries.
2. Select the file location and press the Next button to continue.
3. Highlight the file and then press the Next button to continue.
4. Press the Accept button to confirm the deletion, or press the Go Back button to choose a
different file, or press the Abort button to cancel the operation.
4.6.2 System restore and recovery
The analyzer has several recovery options and file transfer functions available as shown in Figure
4-25. These options allow restore point creation and/or chromatogram data file copy (for offline use)
or deletion, as shown below.


If only option names show, then you do not have the correct permissions to use the backup and
restore options.
NOTICE – Equipment damage or loss of data. Risk of loss of data on USB and the
PGC5000. Stop all schedules before creating a recovery USB or backing up the stream files
to a USB flash drive.
 ACCESS CONTROL LIST: Selecting the Access Control List (ACL) icon displays a dialog box
containing a list of users, passwords, and access levels that is distributed, encrypted and
persisted at each device. The ACL can be modified from a PGC5000 (LUI or RUI), VNSA, or a
STAR Client. If the PGC5000 is secured, only users with supervisory rights can modify the
ACL. If the PGC5000 is unsecured, everyone has the ability to modify the ACL.
NOTICE – Equipment damage or loss of data. Stop all schedules before restoring from a
recovery USB flash drive.
 FACTORY: Selecting the Restore Settings icon restores the analyzer to the factory
configuration. All user configuration changes to the system will be lost.
 USER: Selecting the Save icon creates a User Restore point. The system copies all
configuration files from the working directory to the Restore directory on the analyzer. You
should create a restore point prior to making any changes or updates to the analyzer. Only
one restore point is saved. Creating a second restore point will overwrite the initial restore
point.
Selecting the Restore Settings icon restores the system to the user-created restore point. It
copies the configuration files from the Restore directory to the Working directory of the SBC
and restarts the system.
NOTICE – Equipment damage or loss of data. Creating the Recovery drive takes several
minutes. Wait for the “Creation Complete” message before removing the USB drive. Select
the Eject USB icon on the Setup screen before removing the Recovery drive. Store the
Recovery drive in a safe place.
You must use a USB drive with 32 GB or less. If a USB drive larger than 32 GB is used, the
system will appear to write the data to the drive and give a “Creation Complete” message,
but no data will be on the drive.
 RECOVERY: Selecting the USB Flash Drive Operation icon creates a recovery drive on the USB
flash drive inserted in the Single Board Computer (SBC). This operation takes up to thirty
