ABB 3BHB030310R0001 IGCT high voltage inverter spare parts

From: | Author:Wang | Time :2024-11-22 | 203 visit: | Share:

ABB 3BHB030310R0001 IGCT high voltage inverter spare parts

Table 1: Test objects
Type designation Order number for hardware
RED615 HBDDFEADNLA1BMD11G
REF615 HBFNAEFCNHA1AQB21G
REG615 HBGDBDADNBA1BFG11G
The tests are valid also for other products of 615 series.
Table 2: Basic modules
Description Type number PWB version
HBDDFEADNLA1BMD11G
CPU0007, CPU module 2RCA031146A0001 2RCA024978
PSM0004, PS_H/BO, Power supply module 2RCA025059A0001 2RCA024582
BIO0005, 8BI + 4BO, Binary I/O module 2RCA025501A0001 2RCA024986
AIM0016, 4I + 4BI (IL1 - IL3, Io), Analog input
module
2RCA007128A0001 2RAA005401
AIM0003, 1 mA + 2RTD + 5U (UL1B, UL1 - UL3, Uo),
Analog input module
2RCA025048A0001 2RAA005576
DIS0012, LHMI IEC, Large, LHMI module 2RCA025340A0001 2RAA005579
COM0035, COM LDM (SM LC + 2 × MM LC),
Communication module
2RCA034393A0001 2RCA006780
BPL0001, Backplane module 2RCA006836A0001 2RAA005308
HBFNAEFCNHA1AQB21G
CPU0007, CPU module 2RCA031146A0001 2RCA024978
PSM0003, PS_L/BO, Power supply module 2RCA025058A0001 2RCA024582
BIO0007, 8BI + 3BO, Binary I/O module 2RCA026772A0001 2RCA026480
AIM0016, 4I + 4BI (IL1- IL3, Io), Analog input module 2RCA007128A0001 2RAA005401
AIM0006, 5U + 4BI (UL1B, UL1- UL3, Uo), Analog
input module
2RCA021397A0001 2RCA013877
DIS0011, LHMI IEC , Small, LHMI module 2RCA025209A0001 2RAA005579
COM0032, COM REDY (2 × LC + RJ-45 + FOUART + ARC), Communication module
2RCA025693A0001 2RCA006780
BPL0001, Backplane module 2RCA006836A0001 2RAA005308

HBGDBDADNBA1BFG11G

CPU0007, CPU module 2RCA031146A0001 2RCA024978
PSM0004, PS_H/BO, Power supply module 2RCA025059A0001 2RCA024582
BIO0005, 8BI + 4BO, Binary I/O module 2RCA025501A0001 2RCA024986
AIM0015, 7I (I0 0.2/1 A, IL1 - IL3, IL1B - IL3B), Analog
input module
2RAA005920A0004 2RAA005786
AIM0006, 5U + 4BI (UL1b, UL1 - UL3, Uo), Analog
input module
2RCA021397A0001 2RCA013877
DIS0012, LHMI IEC , Large, LHMI module 2RCA025340A0001 2RAA005579
COM0005, COM IEC (RJ-45 + ARC),
Communication module
2RAA005844A0001 2RAA005402
BPL0001, Backplane module 2RCA006836A0001 2RAA005308
Description Reference Result
Markings and mechanical structure IEC 60255-1
IEC 60255-27
OK
Enclosure class (flush-mounted) IEC 60529 IP 54 front side
IP 10 rear side,
connection terminals
Clearances and creepage distances IEC 60255-5
IEC 60255-27
OK
Table 4: Overload and input tests
Description (IEC 60255-1 and IEC 60255-27) Requirement
Rated current, In 0.2/1 A1) 1/5 A2)
Thermal withstand capability
• Continuously
• For 1 s
4 x In=4 A
100 x In=100 A
4 x In=20 A
100 x In=500 A
Dynamic current withstand
• Half-wave value 250 x In=250 A 250 x In=1250 A
Input impedance < 100 mΩ < 20 mΩ
Rated voltage, Un 60...210 V AC
Burden < 0.05 VA
Voltage withstand
• Continuously
• For 10s
240 V AC
360 V AC
Current sensor input, rated voltage (in secondary
side) 75...2812.5 mV
Continuous voltage withstand 125 V
Input impedance at 50/60 Hz 2-3 MΩ
Voltage sensor input, rated voltage 6...30 kV
Table continues on next page
Description (IEC 60255-1 and IEC 60255-27) Requirement
Continuous voltage withstand 50 V
Input impedance at 50/60 Hz 3 MΩ
Binary inputs
• Operational range
• Current drain
• Power consumption
19.2...300.0 VDC
1.6...1.9 mA
31.0...570.0 mW
1) Residual current
2) Residual current and/or phase current
Table 5: Power supply module tests
Test Description Result
Auxiliary voltage
(IEC 60255-1, IEEE
C37.90-2005)
• PS_H 38...300 VDC
38...264 VAC
No influence
No influence
• PS_L 12...72 VDC No influence
Immunity to voltage dips
(IEC 60255-11)
• PS_H Residual voltage 0%:
38...300 VDC 0...50 ms, normal operation
>50 ms, restart
Residual voltage 40%:
38 VDC
300 VDC
200 ms, restart
200 ms, normal operation
Residual voltage 70%:
38 VDC
300 VDC
500 ms, restart
500 ms, normal operation
Residual voltage 0%:
38 VAC 0...46 ms, normal operation
>46 ms, restart
residual voltage 0%:
48...264 VAC 0...58 ms, normal operation
>58 ms, restart
Residual voltage 40%:
38 VAC
264 VAC
200 ms, restart
200 ms, normal operation
Residual voltage 70%:
38 VAC
264 VAC
500 ms, restart
500 ms, normal operation
Table continues on next page
