ABB 3BHE005555R0101 Synchronous voltage measurement board

From: | Author:Wang | Time :2024-11-22 | 128 visit: | Share:

ABB 3BHE005555R0101 Synchronous voltage measurement board

Test Description Result
• PS_L Residual voltage 0%:
19.2...72 VDC 0...50 ms, normal operation
>50 ms, restart
Residual voltage 40%:
19.2 VDC
72 VDC
200 ms, restart
200 ms, normal operation
Residual voltage 70%:
19.2 VDC
72 VDC
500 ms, normal operation
500 ms, normal operation
Interruptions of auxiliary power
supply voltage
(IEC 60255-11)
• PS_H 38 VDC, 5 s
300 VDC, 5 s
38 VAC, 5 s
264 VAC, 5 s
Shutdown and correct restart
Shutdown and correct restart
Shutdown and correct restart
Shutdown and correct restart
• PS_L 19.2 VDC, 5 s
72 VDC, 5 s
Shutdown and correct restart
Shutdown and correct restart
Ripple in the DC auxiliary voltage
(IEC 60255-11)
Max. 15%, f=2xfn No influence
Gradual shutdown and start-up
(IEC 60255-11)
Shut-down ramp: 60 s
Power off period: 300 s
Start-up ramp: 60 s
Shutdown and correct restart
Reversal of DC power supply
polarity
(IEC 60255-11)
Duration 60 s Correct operation after the test
Power consumption
• PS_H VDC ~12.3 W (nominal)/~ 18.0 W
(max.)
VAC ~13.5 W (nominal)/~ 19.3 W
(max.)
• PS_L VDC ~11.7 W (nominal)/~ 16.9 W
(max.)


Contact type Test (IEC 60255-1 and IEEE
C37.90-2005)
Requirement
Double-pole power outputs with
TCS function
Making capacity:
• Continuous carry 8 A
• Make and carry 3 s 15 A
• Make and carry 0.5 s 30 A
Breaking capacity when L/R ≤40
ms, two contacts connected in
series:
• 48 V DC 5 A
• 110 V DC 3 A
• 220 V DC 1 A
Mechanical withstand capability 10 000 operations
Single-pole power outputs Making capacity:
• Continuous carry 8 A
• Make and carry 3 s 15 A
• Make and carry 0.5 s 30 A
Breaking capacity when L/R ≤40
ms:
• 48 V DC 5 A
• 110 V DC 3 A
• 220 V DC 1 A
Mechanical withstand capability 10 000 operations
Contact type Test (IEC 60255-1 and IEEE
C37.90-2005)
Requirement
Signal output X100:S01 Making capacity:
• Continuous carry 5 A
• Make and carry 3 s 15 A
• Make and carry 0.5 s 30 A
Breaking capacity when L/R ≤40
ms:
• 48 V DC 1 A
• 110 V DC 0.25 A
• 220 V DC 0.15 A
Mechanical withstand capability 10 000 operations
Signal outputs and IRF output Making capacity:
• Continuous carry 5 A
• Make and carry 3 s 10 A
• Make and carry 0.5 s 15 A
Breaking capacity when L/R ≤40
ms:
• 48 V DC 1 A
• 110 V DC 0.25 A
• 220 V DC 0.15 A
Mechanical withstand capability 10 000 operations
