ABB DO880-1 digital output module

From: | Author:Wang | Time :2024-11-29 | 159 visit: | Share:

ABB DO880-1 digital output module

Konformitätserklärung
Declaration of conformity
ABB Automation Products GmbH
D-32425 Minden
erklärt, daß das Produkt
declares that the product
FOUNDATION Fieldbus Linking Device LD 800HSE
FOUNDATION Fieldbus Linking Device LD 800HSE
Geräteart
Type of device
FOUNDATION Fieldbus Linking Device
FOUNDATION Fieldbus Linking Device
mit den Bestimmungen der nachstehenden EG-Richtlinien übereinstimmt:
complies with the requirements of the European Directives :
Referenz-Nr.
Reference-no.
Titel
Title
Angewendete harmonisierte Norm
oder andere Normen / Spezifikationen
Applied harmonized standard or other standards / specifications
89/336/EWG
89/336/EEC
EMV
EMC
EN 61000-6-4
EN 61000-6-2
73/23/EWG
73/23/EEC
NSR
LVD
EN 61010-1
Die Sicherheits- und Installationsanweisungen gemäß Technischer Dokumentation
(User Instructions 3BDD011677) inkl. des zugehörigen Datenblattes (3BDD011675) sind zu beachten.
The safety and installation instructions specified in the Technical Documentation (User Instructions 3BDD011677) incl. the data sheet
(3BDD011675) have to be observed.
ABB Automation Products GmbH
Minden, 06.10.2003
DEAPR
Qualitätssicherung
Quality Assurance
(Lietz)
Diese Erklärung bescheinigt die Übereinstimmung mit den genannten Richtlinien, beinhaltet jedoch keine
Zusicherung von Eigenschaften im rechtlichen Sinne.
This declaration certifies the conformance with the above mentioned directives. Affirmation of attributes in a legal sense is not included.
Die Sicherheitshinweise der zugehörigen Produktdokumentation sind zu beachten.
The safety instructions given in the product documentation have to be observed.


File E234192 Vol. 1 Sec. 1 Page 1 Issued: 2003-02-28
and Report
DESCRIPTION
PRODUCT COVERED:
USL, CNL – Open Type Programmable Controllers, product family MFP,
catalog numbers LD800 HSE, MFP-104/HW#SWB, FC/HW#STD, FC/HW#SWB, FF_LD/HW,
FG_PB_3/HW, FG_CA_3/HW, FG_CO_3/HW, FG_DN_3/HW, all model designations may be
followed by numbers or letters.
GENERAL:
These programmable controllers contain different combinations of
Input/output and bus communication modules. These models are constructed in
accordance with the Standard for Industrial Control Equipment, UL 508 and
intended for connection to class 2 circuitry only.
ENGINEERING CONSIDERATIONS (NOT FOR UL REPRESENTATIVE USE):
CNL - Indicates investigation to Canadian National Standard(s)
C22.2 No. 14-M95.
USL - Indicates investigation to United States Standard UL 508,
(Industrial Control Equipment).
Note: CNL = Canadian National Standards - Listed.
USL = United States Standards - Listed.
RATINGS:
Power supply: max. 24 Vdc, Class 2
Power supply digital I/O: 15 - 30Vdc, Class 2
Max. surrounding air temperature: 50°C
Model designation max. input current
LD 800HSE 200mA
FC/HW#STD 400mA
FC/HW#SWB 400mA
FF_LD/HW 200mA
FG-300/HW#PB 1,000mA
FG-300/HW#CA 800mA
FG-300/HW#CO 800mA
FG-300/HW#DN 800mA
