ABB DP820 pulse frequency module

From: | Author:Wang | Time :2024-11-29 | 59 visit: | Share:

ABB DP820 pulse frequency module

NOMENCLATURE:
Model designation Description
LD 800HSE OEM Version of the FF Linking Device for ABB
FC/HW#STD 4 Control Field Controller Standard
FC/HW#SWB 4 Control Field Controller Stadtwerke Bruneck
FF_LD/HW FF Linking Device
FG-300/HW#PB Fieldbus GatewayProfibus 3-channel
FG-300/HW#CA Fieldbus Gateway CAN 3-channel
FG-300/HW#CO Fieldbus Gateway CAN-open 3-channel

FG-300/HW#DN Fieldbus Gateway DeviceNet 3-channe

CONSTRUCTION DETAILS:
General - The details of construction are covered in the following
photographs and accompanying descriptive pages and illustrations.
Corrosion Protection - All parts are made of corrosion resistant
materials or galvanized plated, painted or equivalent as corrosion
protection.
Tolerances - All indicated dimensions are nominal, unless specified
otherwise.
Spacings - Spacings are not specified since these devices are
intended to be connected to a limited voltage source of supply.
Printed Wiring Material - Any R/C PWB (ZPMV2), whose solder time and
temperature are not exceeded and which can be confirmed in the Recognized
Component Directory. May be provided with conformal coating.
Marking - Markings may be provided in French or English for Canadian
markets. Ink-stamped label permanently secured to the housing, includes
Listee’s name or File number, catalog number and the electrical ratings. The
“Class 2” Marking is part of the elctrical ratings. In addition diagrams and
instructions for installation may be provided.


The figures 1 to 8 show the models listed below. These figures are for

reference use only as the entire circuit is in class 2 circuit entirely.
Model
designation
Included Modules, wich are described following
LD800 HSE MFP/HW#FFLD, FF_MODUL/HW
FC/HW#STD MFP/HW#SWB, MFP-104/HW#SWB, 0PB-PC104-MS
FC/HW#SWB MFP/HW#SWB, MFP-104/HW#SWB, 0PB-PC104-MS
FF_LD/HW MFP/HW#FFLD, FF_MODUL/HW
FG-300/HW#PB MFP/HW#FF_LD, MFP-104/HW#FG, 3 x PB-PC104-MS
FG-300/HW#CA MFP/HW#FF_LD, MFP-104/HW#FG, 3 x CAN-AC1-104
FG-300/HW#CO MFP/HW#FF_LD, MFP-104/HW#FG, 3 x CAN-AC1-104
FG-300/HW#DN MFP/HW#FF_LD, MFP-104/HW#FG, 3 x CAN-AC1-104/DN
All module designations may be followed by numbers or letters.
For all modules and models any combinations of terminal blocks and
connectors are acceptable.
1. Supervisory circuit with battery backup and lithium battery pack
(Module MFP-104/HW#SWB only)- (NWGQ2), this pack provides reverse charging
current protection, cat. no. M41T11MH6 and M4T32-BR12SH6
by ST Microelectronics.
2. Terminal block (XCFR2) - cat. no. MSTB 2,5/3.GF or MC 1,5/3-GF-3,81 or
MC 1,5/3-STF-3,81 or MSTBV 2,5/5-GF-5,98 by Phoenix Contact,
min rated 300V, 5A.
3. Sub D Connectors (ECBT2) - cat. no. 0966 118 7500 or 0966 128 6700
by Harting.
4. RJ45 Connector (DUXR2) - cat. no. SS-6488SA-PG4-BA by Stewart.
5. Sub D Connectors (ECBT2) - cat. no. SDM-009-US91-02/N by E-tec.
