ABB DSTA180 57120001-ET/2 terminal plate

The software and hardware concept is based on

modularity. The software application tasks can be

organized in such a way as to be distributed over

different communication units (CMU boards).

This is possible due to an internal communication

concept that keeps all CMU boards informed about

the contents of the process data interface. There is

one process and system database which is available

in adapted copies for each CMU board.

The internal communication system ensures that

all process data are consistent. The different CMU

boards run the communication tasks for the

connected serial links. This allows the type and

number of different communication links running

on one CMU board to be defined.System perfor mance is defined by the configuration of the CMU

boards.

Communication

The RTU560 has a highly flexible capacity for

adaptation to telecontrol communication proto cols.Due to the standardized internal interface for

system and process information,the integration of

a new protocol is mainly oriented towards the new

protocol component.

The RTU560 is able to communicate with different

hierarchical levels of a network control system,

with subordinated RTUs or any other intelligent

electronic devices (IEDs),or with the test and diagnostic system.

The most important standard protocols supported

by RTU560 for communication with the control

system are:

• IEC 60870-5-101

• IEC 60870-5-104

• DNP 3.0 (also on ethernet)

• Modbus

• RP 570/71

• Indactic 23/ 33/ 35

• TG 800

• Sinaut 8FW

• Conitel 300

For communication with subordinated RTUs and IEDs such as protection

relays,local control units,etc.,the following protocols,among others,are

available:

• IEC 60870-5-101

• IEC 60870-5-102

• IEC 60870-5-103

• IEC 60870-5-104

• DNP 3.0

• SPA-Bus

• Modbus

• RP570/71

• Indactic 21

The connection of the respective

communication lines can be carried

out in several ways:

• Direct links with RS 232-C interfaces

(local communication)

• Voice-frequency telegraphy over leased telecommunication lines,private lines with narrow

bandwidth modems or power line carriers

• Radio links

• Dial-up modem

• Fiber-optic cables

• Digital communication networks

Redundancy

For energy transmission and distribution networks

it is important to maintain the access to stations.

RTU560 manages this requirement by providing

a sophisticated redundancy concept offering the

following features:

• Redundant communication lines or links

• Redundant communication units (CMU)

• Redundant Power Supply
