GE Analog Inputs IC697ALG230 Voltage/Current

From: | Author:Wang | Time :2024-12-26 | 121 visit: | Share:

GE Analog Inputs IC697ALG230 Voltage/Current

Family Catalog Number Description
RX3i CPUs IC695CPU310 300MHz Celeron CPU, 10 MB user memory
IC695CPU315 1 GHz Celeron-M CPU, 20 MB user memory
IC695CPU320 1 GHz Celeron-M CPU, 64 MB user memory
IC695NIU001+
versions –AAAA and
later
1.1 GHz Atom 510 NIU. For information, see the RX3i
Ethernet NIU User’s Manual, GFK-2439
IC695NIU001 300MHz Celeron NIU. For information, see the
PACSystems RX3i Ethernet NIU User’s Manual,
GFK-2439
RX3i CPUs with
embedded Ethernet
Interface1
IC695CPE305 1.1GHz Atom CPU, 5 MB user memory
IC695CPE310 1.1GHz Atom CPU, 10 MB user memory
RX3i Redundancy
CPU
IC695CRU320 1 GHz Celeron-M CPU, 64 MB user memory
RX7i CPUs with
embedded Ethernet
Interface
IC698CPE010 300MHz, Celeron CPU, 10MB user memory
IC698CPE020 700MHz, Pentium CPU, 10 MB user memory,
IC698CPE030 600MHz, Pentium-M CPU, 64MB user memory
IC698CPE040 1800MHz, Pentium-M CPU, 64MB user memory
RX7i Redundancy
CPUs with
embedded
Ethernet Interface
IC698CRE020 700MHz, Pentium CPU, 10 MB user memory
IC698CRE030 600MHz, Pentium-M CPU, 64MB user memory
IC698CRE040 1800MHz, Pentium-M CPU, 64MB user memory


PACSystems CPU models have the following features in common:
■ Programming in Ladder Diagram, Function Block Diagram, Structured Text and C.
■ Floating point (real) data functions.
■ Configurable data and program memory.
■ CPE305 and CPE310 have battery-less retention of user memory non-volatile flash. All other
models have battery-backed RAM for user data (program, configuration, register data, and
symbolic variable) storage and clocks.
■ CPE305 and CPE310 models have battery backup for real time clock (elapsed time clock).
■ Non-volatile built-in flash memory for user data (program, configuration, register data, and
symbolic variable) storage. Use of this flash memory is optional.
■ Configurable Run/Stop mode switch.
■ Embedded RS-232 and RS-485 communications. (CPE305 has only RS-232 communications).
■ Up to 512 program blocks. Maximum size for a block is 128KB.
■ Auto Located Symbolic Variables, which allows you to create a variable without specifying a
reference address.
■ Bulk memory area accessed via reference table %W. The upper limit of this memory area can be
configured to the maximum available user RAM.
■ Larger reference table sizes, compared to Series 90* CPUs: 32Kbits for discrete %I and %Q and
up to 32K words each for analog %AI and %AQ.
■ Online Editing mode that allows you to easily test modifications to a running program. (For details
on using this feature, refer to the programming software online help and Proficy Logic Developer
Getting Started, GFK-1918.)
■ Bit in word referencing that allows you to specify individual bits in a WORD reference in retentive
memory as inputs and outputs of Boolean expressions, function blocks, and calls that accept bit
parameters.
■ In-system upgradeable firmware.
1.3.1 Firmware Storage in Flash Memory
The CPU uses non-volatile flash memory for storing the operating system firmware. This allows
firmware to be updated without disassembling the module or replacing EPROMs. The operating
system firmware is updated by connecting to the CPU with a PC compatible computer and running
the software included with the firmware upgrade kit.
1.3.2 Operation, Protection, and Module Status
Operation of the CPU can be controlled by the three-position Run/Stop switch or remotely by an
attached programmer and programming software. Program and configuration data can be locked
through software passwords. The status of the CPU is indicated by the CPU LEDs on the front of the
module. For details, see “Indicators” for each PACSystems family.
Note: The RESET pushbutton is provided to support future features and has no effect on CPU
operation in the current version.
