GE IC697MDL253 24 VAC Input (32 Points)

VxWorks OS Support — VMISFT-7418 Board Support Package:

The VMISFT-7418 is a Wind River Systems, Inc. certified board support

package (BSP) for GE Fanuc’s series of VMEbus Pentium processorbased computers, which is required to run the VxWorks OS. With the

SBC, VxWorks, the BSP, and other VMEbus equipment from GE Fanuc,

implementations can be created for a wide variety of applications,

including real time factory automation, simulation, instrumentation and

control, and process control and monitoring.

The BSP is linked with VxWorks OS, thus allowing software applications

created with Wind River Systems, Inc.’s development system to load

and run on the particular GE Fanuc SBC hardware being used. Serial

ports, parallel ports, keyboard, text mode video, and Ethernet

transceivers are all supported, as well as floppy and IDE hard disk drives

that can be connected to the computer boards. The BSP provides Flash

boot, NVRAM and timer support.

The BSP allows VxWorks applications to have access to the VMEbus.

When hardware includes single cycle and block transfers using DMA

devices, they are supported by the BSP, as well as interprocessor

communications with mailbox registers. VMEbus interrupt handling and

error handling are supported. Since the VMEbus environment often

contains a mixture of devices from various manufacturers, the byteswapping feature is provided to allow big-endian and little-endian

devices to share data correctly.

QNX OS Support — VMISFT-7417 Board Support Package: The

VMISFT-7417 BSP provides QNX support and includes a VMEbus

manager, user API, and configuration files needed to run the QNX BSP

on GE Fanuc’s VMIVME-7xxx SBC products. This BSP provides

customizable VMEbus access. Using the QNX OS on the VMIVME-7xxx

SBCs provides a computing platform suitable for real time applications.

QNX provides the applications programmer with a real time extensible

POSIX OS.

GE Fanuc’s VMISFT-7417 is designed to tailor QNX’s x86 OS to the

VMIVME-7xxx platform. This combination provides a self-hosted

development environment which runs entirely on the VMIVME-7xxx SBC

boards without requiring any external host systems.

Solaris OS Support — VMISFT-7416 Board Support Package: The

VMISFT-7416 BSP includes everything necessary to allow installation of

the Solaris Intel edition OS (available separately from Sun

Microsystems, Inc.) onto VMIVME-7648 SBC. This BSP includes a nexus

driver for VMEbus access. It allows military and telecommunications

and other applications to take advantage of Sun Microsystems, Inc.’s

Solaris OS on a VMEbus-based Intel SBC. This BSP and the Solaris OS

provides POSIX-compliant real time characteristics.

LynxOS x86 Support — VMISFT-7419 Board Support Package:

The VMISFT-7419 BSP includes all of the device drivers and

configuration tables needed to install the LynxOS x86 development

system (available separately from Lynx Real-Time Systems, Inc.) onto

GE Fanuc’s VMIVME-7648.

Using the LynxOS on the GE Fanuc SBCs provides a computing platform

suitable for hard real time applications. LynxOS provides the

applications programmer with a stable development environment based

on industry-wide standards such as POSIX and Motif.

I/O Support — VMISFT-9450 IOWorks Board Drivers: This driver

supports GE Fanuc’s extensive line of VME I/O boards, and is available

for Windows NT/Windows 2000 and VxWorks. IOWorks board drivers

take advantage of all the key benefits and features of each supported

I/O board and new I/O boards are constantly being added.

IOWorks board drivers contain both a C++ class library and a C function

library that provide a common interface to GE Fanuc I/O products for

reading, writing and configuring. You do not need to know the details of

how an individual board is programmed. For instance, you can use the

SetAttributes function on any supported GE Fanuc board; the

WriteAnalog function controls the output from any GE Fanuc analog

output board; or the GetScanMode function retrieves the scan mode for

any GE Fanuc analog board.

Physical/Environmental Specifications

Dimensions: 6U single slot Eurocard form factor (The VMIVME-7648

uses the “01” copper from our VMIVME-7750 SBC.)

Height 9.2 in. (233.4 mm)

Depth 6.3 in. (160 mm)

Thickness 0.8 in. (20.3 mm)

Power Requirements:

+5 VDC (±5 percent), 6 A (typical), 7 A maximum

+12 VDC (±5 percent), 105 mA (typical), 200 mA maximum

-12 VDC (±5 percent), 50 mA (typical), 75 mA maximum
