GE IC698CRE040 RX7i VME M Class 1.8Ghz Redundant CPU

From: | Author:Wang | Time :2024-12-27 | 178 visit: | 🔊 Click to read aloud ❚❚ ▶ | Share:

GE IC698CRE040 RX7i VME M Class 1.8Ghz Redundant CPU

This manual contains general information about PACSystems CPU operation and product features.
Chapter 1 provides a general introduction to the PACSystems family of products, including new
features, product overviews, and a list of related documentation.
CPU Features & Specifications are provided in Chapter 2.
Installation procedures for the different platforms are described in their respective manuals as
given below:
1. PACSystems RX7i Installation Manual, GFK-2223.
2. PACSystems RX3i System Manual, GFK-2314.
3. RSTi-EP User Manual, GFK-2958.
CPU Programming is covered in PACSystems RX7i, RX3i and RSTi-EP CPU Programmer’s Reference
Manual, GFK-2950. It provides an overview of program structure and describes the various
languages which may be used, their syntax and operation, and provides examples.
CPU Configuration is described in Chapter 3. Configuration using the proprietary Proficy Machine
Edition (PME) programming and configuration software package determines characteristics of CPU,
System and module operation. It also establishes the program references used by each module in

the system. For details on configuration of the embedded RX7i Ethernet interface as well as the rack based RX7i
and RX3i Ethernet Interface modules, refer to PACSystems RX7i, RX3i and RSTi-EP TCP/IP

Ethernet Communications User Manual, GFK-2224.
CPU Operation is described in Chapter 4.
Ethernet Communications and Serial Communications are described in Chapter 5.
Serial I/O, SNP & RTU Protocols are described in Chapter 6.
Performance Data, including Instruction Timing is provided in Appendix A.

User Memory Allocation is described in Appendix B.

Revisions in this Manual

Note: A given feature may not be implemented on all PACSystems CPUs. To determine whether a
feature is available on a given CPU model and firmware version, please refer to the Important
Product Information (IPI) document provided for the CPU version that you are using.
Rev Date Description
AA Sep-
2017
• Addition of support for Media Redundancy Protocol (MRP) on CPE100.
Z May-
2017
▪ Addition of RSTi-EP EPSCPE100 (new product) and updated other relevant sections.
▪ Addition of Simple Network Time Protocol (SNTP), Coordinated Universal Time (UTC), and
Daylight Savings Time (DST) features for CPE305, CPE310, CPE330, and CPE400.
Y Dec-
2016
▪ Added section on CPE400 and incorporated into CPU comparison table (section 2.2). This
section also introduces Field Agent and documents how to set up Embedded Field Agent
for the CPE400 (section 2.2.1.8).
▪ Added section 2.1.6, Embedded PROFINET Controller.
▪ Update of Energy Pack Section 4.11.3 to include ACC403 and compatibility matrix.
▪ Added compatibility mode information for CPE330 with CPU320 & CRU320
X Feb-
2016
▪ Corrected Ethernet Indicators CPE305 & CPE310 table
W Aug-
2015
▪ Addition of support for Ethernet Global Data (Class 1) on CPE330
V Jun-
2015
▪ Addition of RX3i CPE330 (new product) and related Ethernet considerations.
▪ Update of Energy Pack Section 4.11.3 to include ACC402 and compatibility matrix.
▪ Addition of HART® Pass Through feature (see page 7).
▪ Addition of CPU Comparison Charts (Section 2.2 and Section 2.3).
▪ Update of Communications Section (Chapter 5). Added Serial Port Electrical Isolation.
▪ Removed original Chapters 5-11 (chapters dealing with CPU programming) and Chapter
14 (Diagnostics). These are now in PACSystems RX7i and RX3i CPU Programmer’s
Reference Manual, GFK-2950 (Chapters 2-8 and Chapter 9 respectively).
U Nov-
2014
▪ New Appendix (A-3.6) EGD Sweep Impact for Embedded Ethernet Interface on RX3i
CPE305 and CPE310.
T Oct-
2014
▪ Support for OPC UA using embedded Ethernet port in CPE305/CPE310 with CPU firmware
8.20.
▪ Support for Ethernet Global Data (EGD Class 1) using embedded Ethernet port in
CPE305/CPE310 with CPU firmware 8.30 Sweep impact of EGD on Embedded Ethernet
interface. Direct replacement for S90-30 IC693CPU374.
▪ New communications capabilities provided by:
o IC695PNS001 – PROFINET Scanner Module
o IC695GCG001 – Genius Communications Gateway via PROFINET
o IC695EDS001 – Ethernet based DNP3 Outstation
