GE IS220PCLAH1A Core analog input/output for aeroderivative turbines

A.4.1 Mezzanine PCI-X PMC Site 1 Connector and Pinout (J11)

The PMC carries the same signals as the PCI standard; however, the PMC

standard uses a completely different form factor. Tables A-8 through A-10 show

the pinouts for the PMC site connectors.

Figure A-9 Mezzanine PCI-X PMC Site Connector (J11)

Table A-8 Mezzanine PMC Site Connector Pinout (J11)

PMC Connector (J11) PMC Connector (J11)

Left Side Right Side Left Side Right Side

Pin Name Pin Name Pin Name Pin Name

1 JTAG_TCK_2 2 VCC_-12 33 FRAME# 34 GND

3 GND 4 INTA# 35 GND 36 RDY#

5 INTB# 6 INTC# 37 DEVSEL# 38 VCC_5.0

7 BMODE1# 8 VCC_5.0 39 PCIXCAP 40 LOCK#

9 INTD# 10 N/C 41 SDONE# 42 PMC_SB0#

11 GND 12 N/C 43 PAR 44 GND

13 CLK 14 GND 45 VCC_3.3 46 AD[15]

15 GND 16 GNT0# 47 AD[12] 48 AD[11]

17 REQ0# 18 VCC_5.0 49 AD[9] 50 VCC_5.0

19 VCC_3.3 20 AD[31] 51 GND 52 CBE[0]#

21 AD[28] 22 AD[27] 53 AD[6] 54 AD[5]

23 AD[25] 24 GND 55 AD[4] 56 GND

25 GND 26 CBE[3]# 57 VCC_3.3 58 AD[3]

27 AD[22] 28 AD[21] 59 AD[2] 60 AD[1]

29 AD[19] 30 VCC_5.0 61 AD[0] 62 VCC_5.0

31 VCC_3.3 32 AD[17] 63 GND 64 REQ64#

Table A-9 Mezzanine PCI-X PMC Site Connector Pinout (J12)

PMC Connector (J12) PMC Connector (J12)

Left Side Right Side Left Side Right Side

Pin Name Pin Name Pin Name Pin Name

1 VCC_12.0 2 JTAG_TRST# 33 GND 34 N/C

3 JTAG_TMS_2 4 JTAG_TDO 35 TRDY# 36 VCC_3.3

5 JTAG_TDI 6 GND 37 GND 38 STOP#

7 GND 8 N/C 39 PERR# 40 GND

9 N/C 10 N/C 41 VCC_3.3 42 SERR#

11 BMODE2# 12 VCC_3.3 43 CBE[1]# 44 GND

13 PCIB_RESET# 14 BMODE3# 45 AD[14] 46 AD[13]

15 VCC_3.3 16 BMODE4# 47 M66EN 48 AD[10]

17 N/C 18 GND 49 AD[8] 50 VCC_3.3

19 AD[30] 20 AD[29] 51 AD[7] 52 N/C

21 GND 22 AD[26] 53 VCC_3.3 54 N/C

23 AD[24] 24 VCC_3.3 55 N/C 56 GND

25 PMC_IDSEL 26 AD[23] 57 N/C 58 N/C

27 VCC_3.3 28 AD[20] 59 GND 60 N/C

29 AD[18] 30 GND 61 ACK64# 62 VCC_3.3

31 AD16] 32 CBE[2]# 63 GND 64 N/C
