GE IS220PTURH1A Turbine Input/Output

From: | Author:Wang | Time :2024-12-18 | 195 visit: | 🔊 Click to read aloud ❚❚ ▶ | Share:

GE IS220PTURH1A Turbine Input/Output

Table A-10 Mezzanine PCI-X PMC Site Connector Pinout (J13 )
PMC Connector (J13) PMC Connector (J13)
Left Side Right Side Left Side Right Side
Pin Name Pin Name Pin Name Pin Name
1 N/C 2 GND 33 GND 34 AD[48]
3 GND 4 CBE[7]# 35 AD[47] 36 AD[46]
5 CBE[6]# 6 CBE[5]# 37 AD[45] 38 GND
7 CBE[4]# 8 GND 39 VCC_3.3 40 AD[44]
9 VCC_3.3 10 PAR64 41 AD[43] 42 AD[42]
11 AD[63] 12 AD[62] 43 AD[41] 44 GND
13 AD[61] 14 GND 45 GND 46 AD[40]
15 GND 16 AD[60] 47 AD[39] 48 AD[38]
17 AD[59] 18 AD[58] 49 AD[37] 50 GND
19 AD[57] 20 GND 51 GND 52 AD[36]
21 VCC_3.3 22 AD[56] 53 AD[35] 54 AD[34]
23 AD[55] 24 AD[54] 55 AD[33] 56 GND
25 AD[53] 26 GND 57 VCC_3.3 58 AD[32]
27 GND 28 AD[52] 59 N/C 60 N/C
29 AD[51] 30 AD[50] 61 N/C 62 GND
31 AD[49] 32 GND 63 GND 64 N/C
The PMC carries the same signals as the PCI standard; however, the PMC
standard uses a completely different form factor. Tables A-11 through A-14 show
the pinouts for the PMC site connectors.
Figure A-12 Mezzanine PCI-X PMC Site Connector (J21)
Table A-11 Mezzanine PMC Site Connector Pinout (J21)
PMC Connector (J21) PMC Connector (J21)
Left Side Right Side Left Side Right Side
Pin Name Pin Name Pin Name Pin Name
1 JTAG_TCK_2 2 VCC_-12 33 FRAME# 34 GND
3 GND 4 INTA# 35 GND 36 RDY#
5 INTB# 6 INTC# 37 DEVSEL# 38 VCC_5.0
7 BMODE1# 8 VCC_5.0 39 PCIXCAP 40 LOCK#
9 INTD# 10 N/C 41 SDONE# 42 PMC_SB0#
11 GND 12 N/C 43 PAR 44 GND
13 CLK 14 GND 45 VCC_3.3 46 AD[15]
15 GND 16 GNT0# 47 AD[12] 48 AD[11]
17 REQ0# 18 VCC_5.0 49 AD[9] 50 VCC_5.0
19 VCC_3.3 20 AD[31] 51 GND 52 CBE[0]#
21 AD[28] 22 AD[27] 53 AD[6] 54 AD[5]
23 AD[25] 24 GND 55 AD[4] 56 GND
25 GND 26 CBE[3]# 57 VCC_3.3 58 AD[3]
27 AD[22] 28 AD[21] 59 AD[2] 60 AD[1]
29 AD[19] 30 VCC_5.0 61 AD[0] 62 VCC_5.0
31 VCC_3.3 32 AD[17] 63 GND 64 REQ64#


Table A-12 Mezzanine PCI-X PMC Site Connector Pinout (J22)
PMC Connector (J22) PMC Connector (J22)
Left Side Right Side Left Side Right Side
Pin Name Pin Name Pin Name Pin Name
1 VCC_12.0 2 JTAG_TRST# 33 GND 34 N/C
3 JTAG_TMS_2 4 JTAG_TDO 35 TRDY# 36 VCC_3.3
5 JTAG_TDI 6 GND 37 GND 38 STOP#
7 GND 8 N/C 39 PERR# 40 GND
9 N/C 10 N/C 41 VCC_3.3 42 SERR#
11 BMODE2# 12 VCC_3.3 43 CBE[1]# 44 GND
13 PCIB_RESET# 14 BMODE3# 45 AD[14] 46 AD[13]
15 VCC_3.3 16 BMODE4# 47 M66EN 48 AD[10]
17 N/C 18 GND 49 AD[8] 50 VCC_3.3
19 AD[30] 20 AD[29] 51 AD[7] 52 N/C
21 GND 22 AD[26] 53 VCC_3.3 54 N/C
23 AD[24] 24 VCC_3.3 55 N/C 56 GND
25 PMC_IDSEL 26 AD[23] 57 N/C 58 N/C
27 VCC_3.3 28 AD[20] 59 GND 60 N/C
29 AD[18] 30 GND 61 ACK64# 62 VCC_3.3
31 AD16] 32 CBE[2]# 63 GND 64 N/C
