GE IS220PPRFH1A IS220PPRFH1B PROFIBUS® Communication

This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
FCC Class A
NOTE
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
NOTE
Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
Canadian Regulations
The V7768/V7769 Class A digital apparatus comply with Canadian ICES-003.
NOTE
Any equipment tested and found compliant with FCC Part 15 for unintentional radiators or

EN55022 (previously CISPR 22) satisfies ICES-003

Table A-1 V7768 VME Connector Pinout (P1)
Pin
No. Row A Row B Row C Row D Row Z
1 D00 BBSY# D08 +5 V N/C
2 D01 BCLR# D09 GND GND
3 D02 ACFAIL# D10 N/C N/C
4 D03 BG0IN# D11 N/C# GND
5 D04 BG0OUT# D12 N/C N/C
6 D05 BG1IN# D13 N/C GND
7 D06 BG1OUT# D14 N/C N/C
8 D07 BG2IN# D15 N/C GND
9 GND BG2OUT# GND VME_GA[5]# N/C
10 SYSCLK BG3IN# SYSFAIL# VME_GA[0]# GND
11 GND BG3OUT# BERR# VME_GA[1]# N/C
12 DS1# BR0# SYSRESET# N/C GND
13 DS0# BR1# LWORD# VME_GA[2]# N/C
14 WRITE# BR2# AM5 N/C GND
15 GND BR3# A23 VME_GA[3]# N/C
16 DTACK# AM0 A22 N/C GND
17 GND AM1 A21 VME_GA[4]# N/C
18 AS# AM2 A20 N/C GND
19 GND AM3 A19 N/C N/C
20 IACK# GND A18 N/C GND
21 IACKIN# N/C A17 N/C N/C
22 IACKOUT# N/C A16 N/C GND
23 AM4 GND A15 N/C N/C
24 A07 IRQ7# A14 N/C GND
25 A06 IRQ6# A13 N/C N/C
26 A05 IRQ5# A12 N/C GND
27 A04 IRQ4# A11 N/C N/C
28 A03 IRQ3# A10 N/C GND
29 A02 IRQ2# A09 N/C N/C
30 A01 IRQ1# A08 N/C GND
31 -12 V N/C +12 v GND N/C
32 +5 V +5 V +5 V +5 V GND


1 GND +5V SP1_TX CONN[1] CONN[2]
2 USB_P5N GND SP1_RTS# CONN[3] GND
3 USB_P5P N/C SP1_DTR# CONN[4] CONN[5]
4 USB_OC5# A24 SP1_RX CONN[6] GND
5 GND A25 SP1_DCD# CONN[7] CONN[8]
6 USB_P4N A26 SP1_CTS# CONN[9] GND
7 USB_P4P A27 SP1_DSR# CONN[10] CONN[11]
8 USB_OC4# A28 SP1_RI# CONN[12] GND
9 GND A29 RTM_SCONF_GP CONN[13] CONN[14]
10 USB_P3P A30 VCC_5.0 CONN[15] GND
11 USB_P3N A31 -12 V CONN[16] CONN[17]
12 USB_OC3# GND GND CONN[18] GND
13 GND +5 V SATA1_RXN CONN[19] CONN[20]
14 USB_P2N D16 SATA1_RXP CONN[21] GND
15 USB_P2P D17 GND CONN[22] CONN[23]
16 USB_OC2# D18 SATA1_TXN CONN[24] GND
17 GND D19 SATA1_TXP CONN[25] CONN[26]
18 +5 V D20 GND CONN[27] GND
19 +12 V D21 GND CONN[28] CONN[29]
20 GND D22 SATA2_RXN CONN[30] GND
21 N/C D23 SATA2_RXP CONN[31] CONN[32]
22 N/C GND GND CONN[33] GND
23 GND D24 SATA2_TXN CONN[34] CONN[35]
24 N/C D25 SATA2_TXP CONN[36] GND
25 N/C D26 GND CONN[37] CONN[38]
26 GND D27 GND CONN[39] GND
27 N/C D28 GND CONN[40] CONN[41]
28 N/C D29 GND CONN[42] GND
29 GND D30 N/C CONN[43] CONN[44]
30 N/C D31 N/C CONN[45] GND
31 N/C GND N/C GND CONN[46]
32 GND +5 V N/C +5 V GND
