GE IS220PCNOH1A IS220PCNOH1B CANopen® Communication

Please refer to Table 3-1, “PCI Configuration Space Registers,” on page 46 for
more information concerning BAR0.
3.7 CompactFlash Disk (V7768 Only)
The V7768 features an optional onboard CompactFlash mass storage system with
a capacity of up to 8 GByte. This CompactFlash Disk appears to the user as an
intelligent ATA (IDE) disk drive with the same functionality and capabilities as a
“rotating media” IDE hard drive. The V7768 BIOS includes an option to allow the
board to boot from the CompactFlash with user-provided operating system.
3.7.1 Configuration
The CompactFlash Disk resides on the V7768 as the secondary IDE bus master
device (the secondary IDE bus slave device is not assignable).
The V7768/V7769 is capable of booting from a server using Gigabit Ethernet over
a network utilizing the Boot ROM BIOS. The BIOS gives you the ability to
remotely boot the V7768/V7769 using a PXE network protocol. The Ethernet must
be connected through the GbE front panel (RJ45) connector to boot remotely. This
feature allows users to create systems without the worry of disk drive reliability
or the extra cost of adding CompactFlash drives.
3.8.1 Boot BIOS Features
• PXE boot support
• Detailed boot configuration screens
• Optional disabling of local boots
• Dual-boot option lets users select network or local booting


If a GE product malfunctions, please verify the following:
1. Software version resident on the product
2. System configuration
3. Electrical connections
4. Jumper or configuration options
5. Boards are fully inserted into their proper connector location
6. Connector pins are clean and free from contamination
7. No components or adjacent boards were disturbed when inserting or remov ing the board from the chassis
8. Quality of cables and I/O connections
If products must be returned, contact GE for a Return Material Authorization
(RMA) Number. This RMA Number must be obtained prior to any return from
Customer Care.
GE Customer Care is available at: 1-800-433-2682 in North America,
or +1-780-401-7700 for international calls. Or, visit our website at:
www.ge-ip.com
Maintenance Prints
User level repairs are not recommended. The drawings and diagrams in this
manual are for reference purposes only
This chapter provides the applicable information regarding regulatory
compliance for the V7768/V7769.
