ABB New BSD Series A complete range

New BSD Series A complete range,

cutting edge

High Accuracy: Equipped with 131,072 pulses/revolution (17-bit) serial encoder, it can achieve high positioning accuracy and excellent rotational linearity even at low speeds, ensuring precise motor operation and meeting the requirements of applications with stringent positioning accuracy.

High adaptability: Two types of motors, low inertia (3000Rpm) and medium inertia (2000Rpm), with a variety of power options ranging from 100W to 2kW, can be adapted to different work requirements. Different power motors have different torque, speed, current and other parameters, which can meet diversified industrial applications, such as low-power motors for small equipment, high-power motors can be used for large machinery.

Good stability: the motor shaft is equipped with keys, which enhances the stability of the mechanical connection, reduces vibration and displacement during operation, and guarantees the stable operation of the equipment. With vibration resistance, it can withstand vibration of 5g (49m/s²), adapting to the working environment with vibration, reducing the impact of vibration on the performance and life of the motor.

Perfect matching function: the motors with brake have different braking torque, the excitation voltage is 24Vdc, the attraction time and release time are shorter, and the braking power is also different, which can provide suitable braking performance for different applications and ensure the equipment stops safely. Perfectly matched with BSD series servo drives, they work together to achieve the best performance.

Easy to install and use: The document lists the dimensions of each motor model in detail, which is convenient for layout and selection during equipment design and installation.

Applicable industrial scenarios

Scenarios requiring high-precision positioning: Since the motor is equipped with a serial encoder with 131,072 pulses/revolution, it has high positioning accuracy and excellent rotational linearity, which is an obvious advantage in the fields of electronics manufacturing and precision instrument manufacturing. For example, in the manufacture of electronic chips, where the positioning accuracy of components is extremely high, the motor ensures precise operation of the production equipment and improves product quality and productivity.

Scenarios with different requirements for torque and speed: the motors are classified into low inertia (3000Rpm) and medium inertia (2000Rpm), with power ranging from 100W to 2kW, and various torque and speed parameters. In the field of packaging machinery, different packaging tasks may require different torques and speeds. Low-power, high-rpm motors can be used for material conveying in small packaging equipment, while high-power motors with the right torque can meet the operational needs of large packaging machinery. In textile machinery, different processes require different torques and speeds of motors, and this series of motors can meet these variations.

Scenarios with braking requirements: motors with brakes have different braking torques, short attraction times and release times, and are suitable for occasions where frequent starting and stopping is required or where equipment is required to stop quickly. Such as cranes, lifts and other equipment, in the process of operation requires a reliable braking system to ensure safety, this series of motors with brake can meet this demand.

Scenarios that need to adapt to complex working environments: the motors can withstand vibration of 5g (49m/s²), and in some industrial environments where there is vibration, such as mining machinery, construction machinery and other fields, they can also operate stably to ensure that the equipment works normally and to reduce failures caused by vibration.

ABB Sace S.p.A. presents its new BSD servo system, a compact, high performance and easy product.

The BSD servo drive meets the needs of engineers, looking for high-performance, easy and reliable products, and buyers, who have lower and lower budgets to make their products competitive in today’s selective market.

ABB: A “made in Europe” brand, worldwide identified as a synonymous of reliability, quality and security. New BSD servo system by ABB Sace: the perfect partner for any of your application needs

Driver Specifications

• Range from 100 watt to 2 Kw

• Supply: 220 Vac

• Compact servo system and high performances

• Analog speed command +/- 10 Volt

• Analog torque command +/- 10 Volt

• Pulse train command up to 1 Mhz

• Serial encoders from 131.072 pulses/turn (standard

• Anti-vibration filter (patent pending)

• Auto-tuning

• Automatic off-set adjustment

• Notch filters

• Configurable simulated encoder output

• Software windows: BSD Configurator.
