ABB 3BSE010796R1 PM825; PM825 S800 Processor

ABB 3BSE010796R1 PM825;  PM825 S800 Processor

Basic information

product identification

Product ID: 3BSE010796R1

ABB model name: PM825, also known as PM825 S800 processor.

Physical specification details

Net weight of the product: 1kg, this weight parameter has practical reference significance for transportation and installation. During transportation, appropriate packaging materials and transportation methods can be selected based on this to avoid packaging damage or increased transportation costs caused by weight estimation deviations; When installing, the load-bearing capacity of the supporting structure should also be considered to ensure a firm installation.

Product net length/depth: 225mm. This size determines the occupied space of the product in the depth direction of the equipment and is an important basis for the design of the equipment casing and internal layout planning. It is necessary to ensure that the installation position has sufficient depth to accommodate the product, while reserving a certain amount of operating and cooling space.

Product net height: 108mm. The height parameter affects the vertical installation layout of the product, especially in multi-layer installation control cabinets, which need to be coordinated with the height of other equipment to avoid space conflicts and ensure the rationality of the overall layout.

Product net width: 135mm. The width parameter and length/depth jointly determine the planar occupied area of the product. In industrial control cabinets with limited space, it is necessary to plan the installation position reasonably according to this size to improve space utilization.

Classification and Environmental Information

UNSPSC classification: 39120000. UNSPSC (United Nations Standard Product and Service Classification) is a globally recognized product classification system that indicates that PM825 belongs to the category of "industrial control equipment", facilitating internal product classification management, data analysis, and supply chain integration within enterprises.

Category attribution: Belonging to "Drives ￫ Drive options ￫ Legacy controllers ￫ AC80 Controller", the clear category hierarchy indicates that it is an optional accessory for transmission equipment, belonging to the legacy (referring to legacy controllers, i.e. traditional or old controllers) category, belonging to the AC80 controller series, which helps users quickly locate the product in ABB's product system, understand its applicable system environment and related supporting equipment.

WEEE category: Category 5 (small equipment with no external dimensions exceeding 50 centimeters). The WEEE (Waste Electrical and Electronic Equipment) directive requires specialized recycling of such products after disposal to reduce environmental pollution and promote resource recycling. When disposing of discarded PM825, users must comply with relevant environmental regulations and hand it over to qualified professional institutions for disposal. They are not allowed to dispose of it at will.

Precautions for use and maintenance

Static protection: During equipment maintenance, wiring, or replacement, operators should wear anti-static wristbands to avoid static electricity from penetrating sensitive electronic components inside. Release body static electricity before touching the device, and do not touch the circuit board or component pins directly with your hands.

Power connection: Confirm that the voltage, current, and other parameters of the power supply meet the equipment requirements (specific parameters need to refer to the product manual). Before connecting the power supply, check whether there are short circuits, grounding, and other faults in the circuit to avoid equipment burnout caused by power problems. It is recommended to install suitable fuses or circuit breakers in the power circuit as overload and short circuit protection.

Regular inspection: Regularly (such as every quarter) inspect the appearance of the equipment, checking whether the shell is damaged, whether the interface is loose, and whether the heat dissipation holes are blocked. If any abnormalities are found, stop the machine in a timely manner for handling. If necessary, contact professional maintenance personnel for inspection. Do not disassemble the equipment by yourself (non professional disassembly may lead to the expansion of the fault or loss of warranty rights).
