ABB PP846 3BSE042238R1 Human-machine interface

From: | Author:Wang | Time :2024-12-11 | 103 visit: | Share:

ABB PP846 3BSE042238R1 Human-machine interface

System 800xA Asset Optimization highlights include:
■Complete Assct Optimization:Provides a higher return on all plant assets
through optimized remediation work processes and early detection of failure via its
single environment for engineering, operations, and notification.
■Automatic Monitoring of Maintenance Conditions and Automatic Alarms:
Real-time monitoring of asset Key Performance Indicators (KPI's) facilitates fast,
reliable implementation of corrective actions.
■ Plant-Wide Adoption of Predictive and Proactive Maintenance Strategies:
Collects, aggregates, and analyzes real-time plant asset information to provide
advanced warning of degrading performance and impending failure.
■Consistent Reporting of Plant Asset Health Status: Reporting features provide
visualization of current health conditions. Analysis features provide the ability to drill
down to root cause of failure.
■ Reduced Time to Repair through Optimized Work Processes: Integration of
disparate Computerized Maintenance Management System (CMMS) data,calibration
system data, condition monitoring system data, and control system asset data
provides users a single application view, leading to quick and efficient assessment of
maintenance needs and status.
Figure 25.Asset Optimization
Additionally, 800xA Asset Optimization reviews the health and condition of the
Harmony control network. It provides detailed information on Harmony Process
Control units, controllers, bridges, all modules in the system, module/loop faults and
overall performance(Figure 26).
800xA Asset Monitoring leverages the diagnostic information resident in the system's
traditional diagnostic views for Harmony Control Network and individual system
nodes (PCU). These displays provide information about current Harmony equipment
sub-conditions, severity, asset monitor status, fault report availability, and work order
availability when integrated with the plant'sCMMS system.


800xA Production Management provides batch production management solutions,
delivering unsurpassed batch-to-batch consistency, quality, and productivity.These
measurable results are achieved through an unmatched level and scope of batch
control integrated with scheduling, electronic batch records, inventory management,
quality control, HSI, history, and controllers.Whether a process is manual, automated
or both,800xA Production Management offers solutions for stand-alone environments
or for integrated operation with ERP,MES, etc.
The Batch Management component of 800xA Production Management is a powerful
application software package for configuring, scheduling, and managing batch
operations. As such, 800xA Batch Management provides:
Real-time resource management
Flexible on/off-line recipe management
Batch data collection and history integrated with 800xA Information Management
The 800xA Batch Management server supervises execution of control recipe
procedures. The server sends formulation data and issues commands to equipment
phase logic via the PHASEX function block running in Harmony controllers. The
PHASEX block executes the equipment phase logic and communicates status
information to the batch server.
For more details, please refer to the 800xA System Batch Management Overview,
3BUS092077.
Batch Data Manager Tools (from Composer for Phase Logic).Batch data
manager (BDM) is the family of engineering tools for creating, editing, managing,
downloading, and debugging batch equipment phase logic for Harmony systems. At the
heart of BDM is the Batch 90""programming language which enables the engineer to
create equipment phase logic using clear, concise, natural syntax control statements.
Batch 90 layers on top of the regulatory and discrete device control function code
logic of Harmony. Equipment phase logic to change controller set points, turn discrete
devices on and off, change modes, and other equipment supervisory operations is
written in Batch 90. The PHASEX function code provides the programmatic interface
between Batch 90 and regulatory and discrete control configured using INFI 90
function blocks.
