ABB PPC905AE101 3BHE014070R0101 Medium and high voltage frequency conversion cabinet control unit

From: | Author:Wang | Time :2024-12-12 | 69 visit: | Share:

ABB PPC905AE101 3BHE014070R0101 Medium and high voltage frequency conversion cabinet control unit

Isolation data 1SVR 427 014 R0000
Rated insulation voltage Ui
between all isolated circuits
(IEC/EN 60950-1; EN 50178)
Eingang / Ausgang 300 V
Eingang / PE 300 V
Ausgang / PE 50 V
Rated impulse withstand voltage Uimp
between all isolated circuits
(IEC/EN 60950-1; EN 50178)
Eingang / Ausgang 4 kV; 1.2/50 µs
Eingang / PE 2.5 kV; 1.2/50 µs
Ausgang / PE 500 V; 1.2/50 µs
Power-frequency withstand voltage
(test voltge)
(routine test / type test)
Eingang / Ausgang 1.5 kV AC / 3.0 kV AC
Eingang / PE 1.5 kV AC / 3.0 kV AC
Ausgang / PE 500 V DC / 500 V DC
Pollution degree (IEC/EN 60950; EN 50178) 2
Overvoltage category (IEC/EN 60950; EN 50178) II
Standards / Directives 1SVR 427 014 R0000
Product standard IEC/EN 61204
EMC Directive 2004/108/EC
Low Voltage Directive 2006/95/EC
RoHS-Directive 2002/95/EC
Electrical safety EN 50178, EN 60950, UL 60950, UL 508
Protective low voltage SELV (EN 60950)
Electromagnetic compatibility 1SVR 427 014 R0000
Interference immunity to IEC/EN 61000‑6‑2
electrostatic discharge IEC/EN 61000‑4‑2 Level 4 (8 kV / 15 kV)
radiated, radio-frequency, electromagnetic field IEC/EN 61000‑4‑3 Level 3 (10 V/m)
electrical fast transient / burst IEC/EN 61000‑4‑4 Level 4 (4 kV)
surge IEC/EN 61000‑4‑5 Level 4 (2 kV symmetrical)
Level 3 (3 kV asymmetrical)
conducted disturbances, induced by radiofrequency fields
IEC/EN 61000‑4‑6 Level 3 (10 V)
Interference emission IEC/EN 61000‑6‑3
high-frequency radiated IEC/CISPR 22, EN 55022 Class B
high-frequency conducted IEC/CISPR 22, EN 55022 Class B


Characteristic curve of temperature at Uout = 24 V
The switch mode power supply CP‑S 24/5.0 is able to supply at 24 V DC output voltage and at an
ambient temperature of
≤ 40 °C a continuous output current of approx. 7.25 A
≤ 60 °C the rated current of 5 A
At ambient temperatures of:
> 60 °C the output power has to be reduced by 2.5 % per Kelvin temperature increase.
> 70 °C i.e. thermal overload, the device will switch‑off.
If the switch mode power supply is loaded with an output current > 7.25 A, the operating point is
passing through the U/I characteristic curve shown.
