ABB PU515A 3BSE032401R1 Central Processing Unit

From: | Author:Wang | Time :2024-12-12 | 74 visit: | Share:

ABB PU515A 3BSE032401R1 Central Processing Unit

SYN 5200, SYN 5201, SYN 5202 (channel 1), SYN 5302 (channels 1) Step Setting range
Actual value calibration
Nominal voltage 1 V 50 to 130 VAC
Voltage matching (between U1 and U2) 0,1 % + 12 %
Angle matching (SYN 5200 and SYN 5201 only) 1 DEG + 180 DEG
Command generation
Paralleling time 10 ms 0 to 990 ms
Duration of paralleling command 10 ms 50 to 990 ms
Monitoring time 1 s 0 to 99 s
Paralleling conditions
Slip limit* 0,01 % 0 to 6 %
Angle limit (angle window)* 1 DEG 1 to 99 DEG
Maximum voltage difference* 1 % 0 to 40 %
Maximum voltage 1 % 100 to 130 %
Minimum voltage 1 % 50 to 95 %
Note: *Positive and negative limit values can be set separately
Dead bus conditions
Maximum zero voltage for dead bus 1 % 0 to 49 %
Note: The following possibilities - and all combinations thereof - can be allowed or ruled out for paralleling by means of programming:
U1 = dead bus; U2 = dead bus; both sides dead bus
Voltage matcher
Voltage adjustment characteristic 0,01 %/s 0 to 5 %/s
Interval between pulses 1 s 1 to 20 s
Minimum pulse duration 0,01 s 0,05 to 2 s

Note: The length of adjusting pulses is proportional to the voltage difference.
The proportionality factor (0,01 to 5 %/s) is adjustable. Alternatively, it is

possible to work with fixed pulse lengths (0,05 to 2 s),
in which case the interval times are inversely proportional to the voltage difference.

Frequency matcher
Frequency adjustment characteristic 0,01 %/s 0 to 5 %/s
Interval between pulses 1 s 1 to 120 s
Minimum pulse duration 0,01 s 0,05 to 2 s

Note: The length of adjusting pulses is proportional to the slip. The proportionality
factor (0,01 to 5 %/s) is adjustable. Alternatively, it is possible to work

with fixed pulse lengths (0,05 to 2 s), in which case the interval times are inversely proportional to the slip.
General parameters
Blocking time following start signal 1 s 1 to 10 s
Total paralleling time 0,5 min 0,5 to 15 min; OFF
SYN 5100, SYN 5202 (channel 2), SYN 5302 (channels 2) Step Setting range
Slip limit 0,1 % 0,1 to 2 %
Angle limit 5 DEG 5 to 40 DEG
Maximum voltage difference 5 % 5 to 40 %
Maximum zero voltage for dead bus 5 % 0 to 50 %
Nominal voltage 5 V 50 to 130 VAC
Note: The percentages refer to the nominal values


Isolation
Dielectric test IEC 60255-5 2 kV
Impulse voltage test IEC 60255-5 5 kV
Temperature ranges for devices without communication
Transport/storage -40 to +85 °C
Functionable -25 to +70 °C
Operation (compliance with technical data) -10 to +55 °C
Temperature ranges for devices including communication
Transport/storage -10 to +85 °C
Functionable +5 to +70 °C
Operation (compliance with technical data) +5 to +55 °C
Mechanical stability
Vibration: IEC 60255-21-1 10 to 150 Hz; cl. 2
– Vibration response 1 g
– Endurance 2 g
Shocks and bumps: IEC 60255-21-2 class 2
– Shock response 10 g
– Withstand 30 g
– Bump 20 g
Earthquake
– Single axis sine sweep seismic test IEC 60255-21-3
IEEE STD 344-1987
Method A
5 g in each axis
Emission AC mains conducted disturbance CISPR 22 Class B
0,15 to 0,5 MHz: 66...56dB / 56...46dB
0,5 to 5 MHz: 56...46dB
5 to 30 MHz: 60dB / 50dB
Emission, enclosure radiation disturbance CISPR 11 Class A
30 to 230 MHz: 30dB
230 to 1000 MHz: 37dB
Electrostatic discharges IEC 60255-22-2
IEC 61000-4-2
IEEE C37.90.3-2001
Class IV
Contact: 8 kV
Air: 15 kV
Electromagnetic fields IEC 61000-4-16 0 to 150 kHz: 30 V continuous; 300 V for 1 s
IEC 61000-4-6 0,15 to 80 MHz
10 V; 80 % AM
IEC 60255-22-3
IEC 61000-4-3
Frequency sweep:
80 to 1000 MHz: 10 V/m; 80 % AM
1,4...2 GHz: 20 V/m; 80 % AM
Spot frequencies:
80/160/450/900 MHz: 80 % AM; Testing time >10 s
IEEE C37.90.2-2004 25 to 1000 MHz: 20 V/m; 80% AM (max. result. field strength: 35 V/m)
Fast transient IEC 60255-22-4
IEC61000-4-4
Class IV; 4 kV
IEEE C37.90.1-2002
(fast transient)
4 kV common and transverse mode
IEC 61000-4-12 2,5 kV
Surge voltage IEC 61000-4-5 Installation classification: class 3
+ 1 / + 2 kV
Voltage dips IEC 61000-4-11 AC:
30%: 10 ms
60%: 100 ms
>95%: 5000 ms
1 MHz burst disturbance IEC 60255-22-1 Class III
2,5 kV common and transverse
IEEE C37.90.1-2002
(oscillatory)
2,5 kV common and transverse
