ABB PXAH401 3BSE017235R1 industrial control human-computer interaction unit

CE-conformity

EMC-directive 2014/30/EU

Generic standard EN 61000-6-4

EN 61000-6-2

Emission

Immunity

Low voltage directive 2014/35/EU

Safety of information technology

equipment

EN 60950

Product standards

Measuring relays and protection

equipment

Product standard for measuring relays

and protection equipment

Hydro Québéc standard for electronic

equipment and relays

IEEE standard for relays

IEC 60255-6

EN 50263

SN-62.1008d

IEEE C37.90-1989

Degrees of protection in accordance with IEC 60529

Front IP 54

Rear IP 50

Dimensions

SYN 5100

Hat rail mounting (DIN)

See illustration of dimensions SYN 5200, SYN 5201, SYN 5202

SYN 5302

Weight

SYN 5100 0,3 kg

SYN 5200, SYN 5201, SYN 5202 4 kg

SYN 5302 8 kg

PCB designation Type

Communications board IEC 61850 SYN 5009

Communications board SYN 5010

Processor and power supply board (Indication of

device type required, e.g. SYN 5201)

SYN 5011

Basic I/O unit SYN 5012

Processor for channel 2 (synchrocheck) SYN 5013

Extended I/O / seven parameter sets (option) SYN 5014

Bus board for SYN 520x SYN 5015

System control SYN 5020

Bus board for SYN 5302 SYN 5025

Spare parts

Ordering information

When ordering, please state the complete type designation of

the synchronizing unit.

Recommendation

No individual parts are available for the SYN 5100 unit. It is

therefore recommended that an identical, pre-set replacement

unit be kept in stock.

In the case of SYN 520x units, it is recommended that an

identical, pre-set replacement unit be kept in stock.

In the case of the SYN 5302, the following PCB modules are

recommended as spare parts: SYN 5020 system control and

SYN 5014 extended I/O card, if the latter is installed.

SynView is a tool for simple and fast commissioning of

SYNCHROTACT® 5 devices. The PC software runs under

MS® Windows™ NT, 95, 98, 2000, XP and Windows 7 in the

standard languages German, English or French. SynView

consists of five functions explained below:

Parameter tool

All parameter settings are carried out using this tool. The files

can be stored on the PC and copied to other units. Helpful

functions such as comparing parameter settings between

device and PC-file, or the display of recommended setting

values, greatly simplify commissioning and servicing.

Transient recorder tool

The voltage difference and paralleling command from the

last three synchronizing processes are displayed. As such a

separate recorder is unnecessary
