ABB SC510 3BSE003832R1 OCS processor input and output unit

From: | Author:Wang | Time :2024-12-12 | 171 visit: | 🔊 Click to read aloud ❚❚ ▶ | Share:

ABB SC510 3BSE003832R1 OCS processor input and output unit

(A1) EC TYPE EXAMINATION CERTIFICATE
LCIE 02 ATEX 6025 X dated March4,2002
VARIATION 02 ATEX 6025 X/05
(A5) SPECIAL CONDITIONS FOR SAFE USE :
Supplemented by :
-Thermal Conductivity Detector (TCD),Standard Type 002A:
(i) component shall be fitted inside the oven of the analyzer (ii)
component is grounded to the frame of the analyzer in which it
is fitted.
-Overpressure and Purge Control Device:
(i) override feature shall be operated by a special tool or a key
(ii) the user shall ensure the requirements for purge volume
and overpressure when energized. (iii) enclosure is grounded
to the apparatus on which it is fitted (iv) the maximum
capacitance and inductance of the intrinsic safety material
connected to terminals P1-1 and P1-2 can not exceed
respectively 200 nF and 1 mH, the capacitance and self
inductance factor of the connection lines being considered.
-Heater Block, Vaporizer, Type 791:
(i) component shall be fitted inside the oven of the analyzer (ii)
component is grounded to the frame of the analyzer in which it
is fitted (iii) each device shall be sealed and its setting shall not
be modified later.
-Thermal Conductivity Detector (TCD), Type 795 and 798:
(i)component shall be fitted inside the oven of the analyzer (ii)
component is grounded to the frame of the analyzer in which it
is fitted (iii) each device shall be sealed and its setting shall not
be modified later.
-Temperature Program Oven, Type 767:
(i) oven with heater is grounded by the frame of the analyzer.
(ii) each device shall be sealed and its setting shall not be
modified later.
-Flame lonization Detector (FID), Type 794 and 799:
(i) component shall be fitted inside the oven of the analyzer (i)
component is grounded to the frame of the analyzer in which it
is fitted (iii) each device shall be sealed and its setting shall not
be modified later.


(A1)ATTESTATION D'EXAMEN CE DE TYPE
LCIE 02 ATEX 6025 X du 4 mars 2002
AVENANT 02 ATEX 6025X/05
-RÃéchauffeur isothermique type 800:
(i) Ce composant devra être installé a l'intérieur du four de
I'analyseur (ii) Le réglage devra assurer que la température
limite n'est pas dépassée.
-Traversée type 733 et 805 :
(i) température ambiante:0à50C
-Détecteur de flamme photométrique type 804:
(i) inclut dans un four isotherme.
-Four type807:
(i) Installé à l'intérieur d'une envelope EExp
-Piège / Purificateur d'air / Méthaniseur type805:
(i) Type 805-1 et 805-2 utilis©s dans le PGC2008,() Type
805-3 et 805-6 utilisés dans les PGC2203/PGC2004.(ii)
Type 805-4 utilisé dans le PGC2004, (iv) Type 805-5 utilisé
dans la série PGC2000.
-Détecteur à conductivité thermique type 798A:
(i) Ce composant est installé a l"intérieur d'une enveloppe
pressurisée (ii) Ce composant sera relié a la terre par
I'enveloppe de l'analyseur dans lequel il est installé.(iii) La
température ambiante interne de l'enveloppe purgée doit étre
contrôlée et limitée en dessous de la classe de température
(iv) Température ambiante:0á+180°C.
A6)
EXIGENCES ESSENTIELLES EN CE QUI
CONCERNE LA SECURITE ET LA SANTE:
Complétées par:
Epreuves individuelles:
-Module de pressurisation :
L'enveloppe d est soumise à une épreuve de surpression
statique de 13,5 bar minimum
-Four type 767:
Le réchauffeur sera soumis à une épreuve de rifgidite
diélectrique selon la norme EN50019.
-Détecteur d'ionisation de flamme type 794 et 799:
Les enveloppes d sont soumises a une épreuve de
surpression statique de 20 bar minimum
