Brand Background: PDL has been deeply involved in the New Zealand market since 1937 and became a brand under Schneider Electric in 2001, combining local experience with global technology

Product positioning: The ultimate solution for residential circuit protection, targeting the electrician community, balancing installation efficiency, safety, and professionalism

Core concept: Simplify installation process and reduce fault risk through modular design, innovative busbar system and full scenario protection equipment

Core product series and parameters

(1) Core protection equipment

Product Type Key Models Core Parameters Main Functions

Main switch R9S06191/R9S06291/R9S06391 1/2/3P, 100A, IP20, wiring capacity 50mm ², main power isolation, emergency power-off

MCB (miniature circuit breaker) R9F06106-R9F06140 C curve, 6-40A, 1P, 6kA breaking capacity overload and short circuit protection

RCCB (Residual Current Protector) R9R06240/R9R06263 2P, 40/63A, 30mA, A-type leakage protection to prevent electric shock

RCBO (Combination Circuit Breaker) Slim Type: R9D06606-R9D06632

Module 2: R9D08610-R9D08640 6-40A, 30mA, Type A, 6kA breaking capacity integrated with MCU+RCCB function, saving space

AFDD (Arc Fault Detection Device) R9TDB3606-R9TDB3625 6-25A, 1P+N, 6kA breaking capacity for detecting arc faults and preventing electrical fires

SPD (Surge Protective Device) R9L40100/R9L40102 1P, 40kA (8/20 μ s), replaceable fuse core to protect home appliances from voltage surge damage

(2) Innovative Components - MAXBAR Bus System

Core function: Integrated distribution of phase and neutral lines, directly connecting the main switch to RCBO/AFDD without the need for additional wiring

Key parameters: 100A rated current, 230V voltage, IP2X protection (with toothed cover)

Product Type:

With neutral terminal block: R9XPN115N (15 channels, including terminal block and accessories)

Neutral terminal block: R9XPN115 (15 circuits, including connectors and accessories)

Advantages: The installation speed is twice as fast as the traditional RCCB+MCB method, and it supports cutting customized lengths

(3) Shell and accessories

Category Key Model Core Parameter Characteristics

Plastic shell surface installation: R9HSB115S-R9HSB415S

Concealed installation: R9HSB110F-R9HSB415F, 1-4 rows, 10-60 channels, IP40 white RAL9003, with sufficient wiring space reserved

Mini shell R9HME102S/R9HME104S/R9HME106S 2/4/6 channels, IP30， Surface installation suitable for small circuit protection

Core accessory terminal block: SEA9TB1001

Identification label: R9ACIL

Locking device: 26970 compatible with Resi9 full range equipment to meet wiring, labeling, and safety locking requirements

Core advantages of the product

(1) Performance advantages

Durability: All equipment passes 10k electrical cycle and 20k mechanical cycle tests (except for module 2 RCCB)

Environmental adaptability: Operating temperature range of * * -25 ° C to+70 ° C * *, supporting pollution level 3 and tropical level B

Protection level: IP20 for individual devices, IP40 for modular enclosures to prevent accidental contact

(2) Installation advantages

Flexible wiring: All devices support top/bottom entry (except for 2 RCBO modules)

Efficiency improvement: MAXBAR busbar eliminates RCBO feeder line, doubling installation speed

Compatibility: 35mm DIN rail installation, compatible with Resi9 full range modular equipment

(3) Safety and Sustainable Advantages

Multiple protection: covering risks of overload, short circuit, leakage, arc fault, and surge in all scenarios

Standard compliance: Complies with series standards such as AS/NZS 60898 and AS/NZS 61009

Sustainability: Certified with Green Premium, RoHS/REACH compliant, providing transparency on material composition and environmental impact

Technical details and selection

(1) Release Curve and Capacity Reduction Table

Release curve: Both MCB and RCBO are C-curves (5-10In), suitable for most residential scenarios

Capacity reduction feature: Automatic adjustment of current rating under high temperature environment, such as reducing the capacity of 40A MCB to 33.6A at 70 ° C

(2) Selection criteria

Circuit type: Lighting circuit selected 6-10A MCB, socket circuit selected 16-20A RCBO

Equipment requirements: EV charging station, air conditioner with 25-32A RCBO, sensitive electronic devices need to be equipped with SPD

Security upgrade: It is recommended to install AFDD in old residential buildings to prevent arc fires caused by aging wiring

Applicable scenarios

New residential construction: The entire range of equipment is adapted to the overall circuit layout, supporting new demands such as smart devices and EV charging stations

Residential renovation: Slim type RCBO saves space and adapts to upgrading old distribution boxes

Terminal protection: SPD protects household appliances such as refrigerators and washing machines, AFDD protects hidden circuit safety
