ABB DI810 digital input module

When the tension electronics has been powered on for the first time after delivery, you are asked
to SetLanguage and then to SetUnit. These two settings must be performed to be able to
proceed with the rest of the setup. Language and unit can be changed later on if desired.
3.8 Performing a Fast Setup
The fast setup guides you through a minimum number of steps to set up the tension electronics.
You are asked to answer some questions and to enter desired values. These selections and
parameter settings must be made to get the tension electronics ready for measurement.
Only a limited number of selections and parameter settings are set in the fast setup. All other
parameters are set as factory default values. See Appendix A.4 Factory Default Settings.
The fast setup can be made in two ways, depending on how the wrap gain is set.
The wrap gain can be set by selecting “HangWeight” or “EnterWrapGain”.
• Using Hanging Weights, see Section 3.8.1.
• Using Wrap Gain, see Section 3.8.2.
Hanging Weights and Wrap Gain are explained in Section 3.12.5.
1 Select desired language from the list with and
. English is set as default.
Confirm with .
2 Select desired presentation unit from the list with
and . N (Newton) is set as default.
Confirm with .
3 The menu SetWebWidth will only be available when
the selected unit is N/m, kN/m, kg/m or pli.
Default Web Width is 2m (78,740 inch).
4 Select number of decimals from the list with
and .
Confirm with .
5 Press to start the fast setup sequence.
See Section 3.8.
If you want to make a complete setup, go to the
separate setup menus by pressing .

See Section 3.11.

Performing Fast Setup using Hanging Weights

The simplest method to set the wrap gain in this tension system is to use a known weight that
loads the center of the roll with a rope that follows the web path exactly.
Figure 3-1. Setting Wrap Gain with Hanging Weights (example of installation)
Follow the steps below to run a fast setup using hanging weights.
1 Press for 5 seconds to go to the FastSetUp menu.
2 Press to start the fast setup sequence.
3 The menu SetWebWidth will only be available when the
selected unit is N/m, kN/m, kg/m or pli.
Default Web Width is 2m (78,740 inch).
4 Select HangingWeights from the list with and .
Confirm with .
5 Select the number of load cells that support the roll (2 or
Single Side A or Single Side B) from the list with or .
Confirm with .
6 Check the nominal load on the load cell name plate.
Select nominal load from the list with or .
Confirm with .
7 Zero set is used to compensate for load cell zero signal and
tare weight.
Zero set must be done with no tension applied to the roll.
8 1. Check that no load is applied on the roll.
2. Press to zero set. “ActionDone” is shown on the
display for one second to confirm the zero setting action.
