Home >> ABB >> ABB REB500 Distributed busbar protection
Current position：

Brand
ABB REB500 Distributed busbar protection
❤ Add to collection

ABB REB500 Distributed busbar protection

+86-15305925923
Mr.Wang
wang@kongjiangauto.com

• Low-impedance busbar protection

• Stub and T-zone protection

• High functional reliability due to two inde pendent measurement criteria:

- stabilized differential current algorithm

- directional current comparison algorithm

• Phase-by-phase measurement

• Reduced CT performance requirements

• High through-fault stability even in case of

CT saturation

• Full solid-state busbar replica

• No switching of CT circuits

• Only one hardware version for

￥38388.00
￥38387.00
Weight：8.800KG
Quantity：
(Inventory: 50)
Consultation
Accessories
  • ABB-07KR51-Centr
    Original ：￥11222.00
    With a price ：￥11222    		 Quantity
  • ABB-3BSE020269R0
    Original ：￥16364.00
    With a price ：￥16364    		 Quantity
    •
    Original ：￥
    0.00

      With the total price ：￥
    0.00
Product parameters
  • Telephone:+86-15305925923
  • contacts:Mr.Wang
  • Email:wang@kongjiangauto.com
Description

• Low-impedance busbar protection

• Stub and T-zone protection

• High functional reliability due to two inde pendent measurement criteria:

- stabilized differential current algorithm

- directional current comparison algorithm

• Phase-by-phase measurement

• Reduced CT performance requirements

• High through-fault stability even in case of

CT saturation

• Full solid-state busbar replica

• No switching of CT circuits

• Only one hardware version for



ABB REB500 Distributed busbar protection

Distributed busbar protection REB500
including line and transformer protection
Main features • Low-impedance busbar protection
• Stub and T-zone protection
• High functional reliability due to two inde pendent measurement criteria:
- stabilized differential current algorithm
- directional current comparison algorithm
• Phase-by-phase measurement
• Reduced CT performance requirements
• High through-fault stability even in case of CT saturation
• Full solid-state busbar replica
• No switching of CT circuits
• Only one hardware version for
- 1 and 5 A rated currents
- all auxiliary supply voltages between
48 V DC and 250 V DC
- nominal frequencies of 50, 60 and 16.7 Hz
• Short tripping times independent of the
plant’s size or configuration
• Centralized layout: Installation of hardware
in one or several cubicles
• Distributed layout: Bay units distributed
and, in the case of location close to the
feeders, with short connections to CTs, iso lators, circuit breakers, etc.
• Connections between bay units and central
unit by fiber-optic cables
- maximum permissible length 1200 m
- for distributed and centralized layout
• fiber-optic connections mean interference proof data transfer even close to HV power
cables
• Replacement of existing busbar protection
schemes can be accomplished without re strictions (centralized layout) in the case of
substation extensions e.g. by a mixture of
centralized and distributed layout
• Easily extensible
• User-friendly, PC-based human machine
interface (HMI)
• Fully numerical signal processing
• Comprehensive self-supervision
• Binary logic and timer in the bay unit
• Integrated event recording
• Integrated disturbance recording for power
system currents
• A minimum of spare parts needed due to
standardization and a low number of vary ing units
• Communication facilities for substation
monitoring and control systems via
IEC 61850-8-1, IEC 60870-5-103 and LON
• IEC 62439 standard redundant station bus
communication
• IEC 61850-9-2 LE process bus communi cation
• Cyber security to support
- User Access Management
- User Activity Logging
Options
• Breaker failure protection (also separately
operable without busbar protection)
• End fault protection
• Definite time overcurrent protection
• Breaker pole discrepancy
• Current and voltage release criteria
• Disturbance recording for power system
voltages
• Separate I0 measurement for impedance grounded networks
• Communication with substation monitoring
and control system (IEC 61850-8-1 /
IEC 60870-5-103 / LON)
• Internal user-friendly human machine inter face with display
• Redundant power supply for central units
and/or bay units
Additional
main features
REB500sys combines the well-proven numer ical busbar and breaker failure protection
REB500 of ABB with Main 2 or back-up pro tection for line or transformer feeders. The
Main 2 / Group 1 or back-up protection is
based on the well-proven protection function
library of ABB line and transformer protection
for 50, 60 and 16.7 Hz.
Main 2 / back-up bay protection
• Definite and inverse time over- and under current protection
• Directional overcurrent definite and inverse
time protection
• Inverse time earth fault overcurrent protec tion

• Definite time over- and undervoltage pro tection

Distributed busbar protection REB500

including line and transformer protection
• Three-phase current and three-phase volt age plausibility
Main 2 / back-up bay protection:
Line protection
• High-speed distance protection
• Directional sensitive earth fault protection
for grounded systems against high resis tive faults in solidly grounded networks
• Directional sensitive earth fault protection
for ungrounded or compensated systems
• Autoreclosure for
- single-pole / three-pole reclosure
- up to four reclosure sequences
• Synchrocheck with
- measurement of amplitudes, phase
angles and frequency of two voltage
vectors
- checks for dead line, dead bus, dead
line and bus
Group 1 / back-up bay protection:
Transformer protection
• High-speed transformer differential protec tion for 2- and 3-winding and auto-trans formers
• Thermal overload
• Peak value over- and undercurrent protec tion
• Peak value over- and undervoltage protec tion
• Overfluxing protection
• Rate of change frequency protection
• Frequency protection
• Independent T-Zone protection with trans former differential protection
• Power protection
Application REB500
The numerical busbar protection REB500 is
designed for the high-speed, selective protec tion of MV, HV and EHV busbar installations
at a nominal frequency of 50, 60 and 16.7 Hz.
The structure of both hardware and software
is modular enabling the protection to be easily
configured to suit the layout of the primary
system.
The flexibility of the system enables all config urations of busbars from single busbars to
quadruple busbars with transfer buses, ring
busbars and 1½ breaker schemes to be pro tected.
In 1½ breaker schemes the busbars and the
entire diameters, including Stub/T-Zone can
be protected. An integrated tripping scheme
allows to save external logics as well as wir ing.
The capacity is sufficient for up to 60 feeders
(bay units) and a total of 32 busbar zones.
The numerical busbar protection REB500
detects all phase and earth faults in solidly
grounded and resistive-grounded power sys tems and phase faults in ungrounded systems
and systems with Petersen coils.
The main CTs supplying the currents to the
busbar protection have to fulfil only modest
performance requirements (see page 18). The
protection operates discriminatively for all
faults inside the zone of protection and
remains reliably stable for all faults outside the
zone of protection.
REB500sys
The REB500sys is foreseen in MV, HV and
EHV substations with nominal frequencies of
16.7, 50 Hz or 60 Hz to protect the busbars
and their feeders. The bay protection func tions included in REB500sys are used as
Main 2 / Group 1 - or back-up protection.

The system REB500sys is foreseen for all sin gle or double busbar configurations
(Line vari ants L-V1 to L-V7 and Transformer variant T V1 to T-V4). In 1½ breaker configurations,

variant L-V5 can be used for the bay level
functions autoreclosure and synchrocheck.
The capacity is sufficient for up to 60 feeders
(bay units) and a total of 32 busbar zones.

The REB500sys detects all bus faults in sol idly and low resistive-grounded power sys tems,
all kind of phase faults in ungrounded

and compensated power systems as well as
feeder faults in solidly, low resistive-grounded,
compensated and ungrounded power sys tems.
The protection operates selectively for all
faults inside the zone of protection and
remains reliably stable for all faults outside the
zone of protection.
REB500sys is perfectly suited for retrofit con cepts and stepwise upgrades. The bay unit is
used as a stand-alone unit for bay protection
functions (e.g. line protection, autoreclosure

and synchrocheck or 2- and 3 winding trans former protection or autonomous T-zone pro tection).
The central unit can be added at a

later stage for full busbar and breaker failure
protection functionality.
  • Alcatel Lucent 1660SM OMSN (Optical Multi Service Node) series next-generation SDH equipment
  • ALCATEL-LUCENT 9500 MICROWAVE PACKET RADIO
  • Atlas Copco MT Focus 6000 Tightening Controller
  • Atlas Copco Power MACS 4000 Fixed Nut Runner (Servo Tightening Shaft) Control System
  • Atlas Copco Neos compressor specific frequency converter
  • Atlas Copco Power Focus 8 (PF8) Series New Generation Tightening Controller Platform
  • Atlas Copco Power Focus 4000 Controller
  • Atlas Copco Power Focus 3000 Controller
  • Atlas Copco ETV S7 (ETV S7-200 13CTADS, 40-200 Nm) electric angle nut tightening machine
  • Atlas Copco SRTT-B Fixed Reaction Torque Sensor
  • Atlas Copco ACTA4000/3000 is a portable torque analysis and calibration instrument
  • Atlas Copco Tensor STB Wireless Tightening Tool
  • Atlas Copco PF4000 Setup Guide
  • Atlas Copco Power Focus 6000 Pocket Guide
  • Atlas Copco ZR-ZT 110-275/132-315 VSD oil-free screw air compressor
  • Atlas Copco PowerMACS 4000 Tightening Control System
  • Atlas Copco Elektronikon MK5 Swipe Controller
  • Atlas Copco Tensor ES electric tightening tool paired with Power Focus 600 controller
  • ADLINK STC2-AL/KL series intelligent touch computer
  • ADLINK STC-15W04 industrial touch all-in-one machine
  • ADLINK SP2- EHL series fanless open panel PC
  • ADLINK PXIS-2719A 19 slot 3U PXI chassis
  • ADLINK PXIe-9908 8-channel four quadrant high-density source measurement unit SMU (Source Measure Unit) PXIe module
  • ADLINK PXIe-9852 2-channel 14 bit, up to 200 MS/s synchronous sampling PXIe high-speed digitizer
  • ADLINK PXIe-9848 8-channel 14 bit, up to 100MS/s synchronous sampling PXIe high-speed digitizer
  • ADLINK PXIe-9834 4-channel 16 bit, up to 80MS/s synchronous sampling PXIe digitizer
  • ADLINK PXIe-9529H is an 8-channel 24 bit, 256kS/s synchronous sampling dynamic signal acquisition PXIe module
  • ADLINK PXIe-3988 3U PXI Express Zero Slot Embedded Controller
  • ADLINK PXIe-3987/3977/3937 PXI Express Zero Slot Embedded Controller
  • ADLINK PXIe-3987 PXI Express Embedded Controller
  • ADLINK PXIe-3988/3987/3977/3937-TL PXI Express Embedded System Controller
  • ADLINK PXI-2020/PXI-2022 Synchronous Sampling Multi functional PXI Data Acquisition Card
  • ADLINK DAQ-20XX/PXI-20XX series 4-channel synchronous multifunctional data acquisition card
  • ADLINK PXES-2788 series high-performance and high-power PXIe chassis
  • ADLINK PXES-2785 18 Slot PXI Express Chassis
  • ADLINK PXES-2780 18 Slot PXI Express Chassis
  • ADLINK PXES-2596 Gen3 9-slot PXI Express chassis
  • ADLINK PXES-2590 9-slot PXI Express chassis
  • ADLINK PXES-2314T Thunderbolt 3 Compact 4-slot PXI Express Chassis
  • ADLINK PXES-2301 6-slot PXI Express chassis
  • ADLINK PCIe U300 series USB3 Vision image acquisition host card
  • ADLINK PCIe PXIe 8565 PCIe to PXIe Remote Expansion Kit
  • ADLINK PCIe GIE74V 4-channel GigE Vision acquisition card
  • ADLINK PCIe - GIE7x Series PCIe x4 Interface GigE Vision PoE+Gigabit Network Image Capture Card
  • ADLINK PCIe CPL64V PCIe Gen3 x4 specification Camera Link image acquisition card
  • ADLINK PCIe CPL64 PCIe x4 Interface Camera Link Image Capture Card
  • ADLINK PCIe 8560+PXI 8565 PCI Express to PXI Remote Bus Expansion Kit
  • ADLINK PCIe 8332/PCIe 8334/PCIe 8338 EtherCAT Master Station Motion Controller
  • ADLINK PCIe 7432 bus industrial isolated digital I/O board
  • ADLINK PCIe 7256 Industrial Digital I/O Board
  • ADLINK PCIe‑833x（PCIe‑8332 / 8334 / 8338）PCIe EtherCAT Master Motion Controller
  • ADLINK PCIe -10GPoE Dual Channel PCIe Gen3 PoE+10GigE Vision Image Acquisition Card
  • ADLINK PCI-8254/PCI-8258 High end 4/8-axis Advanced Motion Control Card
  • ADLINK PCI-8158/PCI-8154 Modular Architecture Advanced Pulse Motion Control Card
  • ADLINK PCI-8134A entry-level 4-axis pulse servo/stepper motion control card
  • ADLINK PCI-725X Series Relay Output and Isolation Digital Input Board
  • ADLINK PCI-6308 series isolated analog output board
  • ADLINK PanKonix ® Series industrial HMI all-in-one machine
  • ADLINK NuDAM-6100 series DIN rail installation, RS-485 bus distributed IO module
  • ADLINK NuDAM-6000 complete distributed RS-485 acquisition and control system
  • ADLINK NEON-2000-ONO series AI intelligent camera
  • ADLINK NuDAM-65xx Communication Module
  • ADLINK NuDAM-60xx Series Digital I/O Modules
  • ADLINK MXE-5300 series fanless embedded computer
  • ADLINK MXE-310 Series Rugged and Compact edge computing Device
  • ADLINK MXE ‑ 230 series ultra compact fanless Alder ‑ Lake ‑ N platform industrial edge computer
  • ADLINK MXE-210 series fanless X86 embedded industrial computer
  • ADLINK MXC-3300/MXC-3340 Fanless Scalable Embedded Industrial Computer
  • ADLINK MXA-312M Ultra Compact Edge AI Computer User Manual
  • ADLINK MXA-200 Industrial IoT Energy Gateway
  • ADLINK MVP-6200 series fanless expandable industrial computer
  • ADLINK MVP-6100 series expandable fanless industrial computer
  • ADLINK MVP-5200 series fanless industrial computer
  • ADLINK MVP-5100 series fanless industrial computer
  • ADLINK MVP-3100 series fanless embedded machine
  • ADLINK MNET-J3/S23/MIA/DA2/SAN single axis Motionnet distributed motion module
  • ADLINK MNET-4XMO/MNET-4XMO-C distributed 4-axis motion control module
  • ADLINK MCM-216/MCM-218 Independent Ethernet Distributed Device Status Monitoring DAQ
  • ADLINK LPCIe-8124-C 4-channel high-speed trigger encoder acquisition card
  • ADLINK IM/OM series industrial touch display
  • ADLINK GW-01 is compatible with PLC industrial IoT gateway
  • EURESYS Grablink Full Series Image Acquisition Cards
  • ADLINK Express HL COM Express Type6 Core Module
  • ADLINK EOS-2000 4-channel analog embedded visual controller
  • ADLINK EOS-1200 4-channel Gigabit PoE Embedded Vision System
  • ADLINK ECS-8582-4S ExpressCard to PCI Expansion System Manual
  • ADLINK DIN-814P-A4 4-axis dedicated motion terminal board
  • ADLINK DIN-814M-J3A 4-axis dedicated motion adapter terminal board
  • ADLINK DIN-814-GP Reference Guide
  • ADLINK DIN-812M Terminal Block Installation Manual
  • ADLINK DIN-814Y Terminal Board
  • ADLINK DAQ/DAQE/PXI-250x series multifunctional analog output acquisition card
  • ADLINK DAQ/DAQE/PXI-220x series multifunctional acquisition card
  • ADLINK cPCI-9116 3U CompactPCI 64 channel 16 bit 250KS/s analog acquisition card
  • ADLINK cPCI/PCI-8554+R multifunctional counting/timing card
  • ADLINK 743X series isolated digital IO board
  • ADLINK cPCI-3534/cPCI-3544/cPCI-3538 series serial port module
  • ADLINK cPCI-3534/3544/3538 series CompactPCI serial port module
  • Euresys Coaxlink Full Series CoaXpress Image Capture Cards
  • ADLINK AMP-304C High end 4-axis Pulse Motion Control Card
  • ADLINK AMP-104C Four Axis Pulse Motion Control Card
  • ADLINK NEON-1020/NEON-1040 Smart Camera
  • ADLINK USB-7230/USB-7250 Isolated Digital I/O Module
  • ADLINK SP-15W03 15.6-inch intelligent all-in-one machine
  • ADLINK DIN-825-4P0 Terminal Board
  • ADLINK USB/LPCI/LPCIe-3488A GPIB interface card
  • ETEL TMB+series standard torque motor
  • ADLINK Angelo RTV series multi-channel real-time video capture card
  • ADLINK PCIe FIW Series 1394b Image Acquisition Card
  • ADLINK 6208/6216-GL series analog output card
  • ADLINK PCI/cPCI -/LPCI -/LPCIe-723X series 32 channel isolated digital I/O board
  • ADLINK PCI-9118 series multifunctional DAQ card
  • ADLINK PCI-9114 (A) Multi functional PCI Data Acquisition Card
  • ADLINK PCI-7440 series (PCI-7442/7443/7444) high-density isolated digital I/O cards
  • ADLINK PCI/LPCI/LPCIe/cPCI-7250 series relay isolation digital IO board
  • Advantech PCI-1610 Series 4-port RS232 PCI Serial Port Card
  • ADLINK NEON-1000-MDX series AI intelligent camera
  • ADLINK MXE-1300 series industrial fanless industrial control computer
  • ADLINK MXE-200/200i Fanless Embedded Computer
  • ADLINK LPCIe/LPCI/USB-3488A GPIB interface card
  • ETEL Linear Motors Product Manual
  • ETEL IL+Ironless/LM Iron Core Linear Motor
  • ETEL DSC Series (DSC2P/DSC2V/DSCDP/DSCDL/DSCDM) Operation and Software Manual
  • ETEL DSCDL Dual Axis Digital Direct Drive Controller Hardware Manual
  • ETEL DSB2-P Digital Servo Amplifier
  • ETEL DSC Series Digital Position Controller Operating Software Manual
  • DFI HD636-H81CS ATX Industrial Motherboard
  • ADLINK DAQ/DAQE/PXI-20xx series multifunctional synchronous acquisition card
