ABB PHCBRCPBA10000 PBA 100 Processor Bus Adapter for Hnet Connection

ABB PHCBRCPBA10000 PBA 100 Processor Bus Adapter for Hnet Connection

Basic Information

Model number: PHCBRCPBA10000.

Name: PBA 100 Processor Bus Adapter for Hnet Connection, which specifies that it is a PBA 100 Processor Bus Adapter for Hnet Connection.

Place of Origin: According to the information, the place of origin is Sweden.

Dimensions and weight: Dimensions are approximately 7.0 inches × 2.0 inches × 5.0 inches, i.e. 17.8cm × 5.1cm × 12.7cm, and weight is approximately 0.2kg.

Functional Features

Bus Connection and Adaptation: The adapter is designed for Hnet network and can achieve stable connection between the processor and Hnet bus. It can convert the signals from the processor into a format suitable for transmission on the Hnet bus, and also convert the signals received on the bus into a form recognisable by the processor to ensure the accurate transmission of data between the two, so as to achieve effective data interaction between different devices through the Hnet network.

Data Processing and Transmission: Equipped with data processing and optimisation functions, it is able to perform operations such as caching, checking and error correction on the transmitted data to improve the reliability and stability of data transmission. In terms of data transmission, it supports high-speed data transmission to meet the demand for rapid transmission of large amounts of real-time data in industrial automation systems and ensure the efficient operation of the system.

Redundancy support: The PBA 100 processor bus adapter is necessary for the redundant configuration of the B RC 100, which is able to work in conjunction with other devices, automatically switching to the standby device or link when the main device or link fails to ensure the continuity and reliability of the system, reducing the production interruption time due to equipment failure.

Application Fields

Industrial automation control system: It is widely used in all kinds of industrial automation scenarios, such as production process control in chemical, petroleum, electric power, metallurgy and other industries. In these systems, it can connect different controllers, sensors, actuators and other devices to the Hnet network to achieve centralised monitoring and automated management of the production process, improving production efficiency, product quality and equipment reliability.

Smart factory construction: It is an important part of building smart factory network architecture. In a smart factory, a large number of intelligent devices and systems need to be interconnected, the PBA 100 adapter through the Hnet connection, can achieve seamless communication and data sharing between the devices, for the realization of the factory's intelligent production, optimization of production processes, and improve the efficiency of energy use to provide strong support.

Main features

· 24 digital inputs with LED displays

· 16 digital transistor outputs with LED displays

· 8 digital inputs/outputs with LED displays

· 8 individually configurable analog inputs 0...10 V, 0...5 V, ±10 V, ±5 V, 0...20 mA, 4...20 mA, differential inputs, Pt100 (2-wire or 3-wire), the analog inputs are also individually configurable as digital inputs

· 4 individually configurable analog outputs ±10 V, 0...20 mA, 4...20 mA

· 2 counters for counting frequencies up to 50 kHz, configurable in 7 different operating modes · 1 CS31 system bus interface for system expansion

· 1 interface for connecting communication modules (e.g. 07 KP 90)

· 2 serial interfaces COM1, COM2

– as MODBUS interfaces and

– for programming and test functions

· Real-time clock

· LEDs for displaying operating conditions and error messages

· Detachable screw-type terminal blocks

· Fastening by screws or by snapping the device onto a DIN rail

· The lithium battery 07 LE 90 can be put into the battery compartment in order to

– store and backup the user program in the RAM

– store and backup data which is additionally contained in the RAM, e.g. the status of flags

– backup the time and date (real-time clock)

· RUN/STOP switch for starting and aborting the program execution

· Extensive diagnosis functions

– self-diagnosis of the basic unit

– diagnosis of the CS31 system bus and the connected modules
