FOXBORO P0973JM The 24-Port Copper managed switch
FOXBORO P0973JM The 24-Port Copper managed switch
OVERVIEW
The 24-Port Copper managed switch (P0973JM) provides 24 100Base-TX ports with RJ-45 connectors, two fixed 10/100/1000 Ethernet ports and two 1000Base-X uplink (ISL) Gigabit (SFP) ports.The switch allows high performance, full-featured layer-2 Ethernet switching in small to medium-sized network applications, as well as high performance direct end-station connectivity.
FEATURES
The 24-Port Copper managed switch features:
24 ports of 100Base-TX (RJ-45)
Two fixed RJ-45 10/100/1000 ports, configurable for 100Base-Tx or 1000Base-TX for devices or 1000Base-TX for (ISL) uplink ports
Two 1000Base-X uplink Gigabit (SFP) ports
Full-duplex operation
Supports VLAN configurations
Configuration tasks through a local console port, and monitoring through any SNMP/RMON based management application.
Port mirroring technology and diagnostics that allow local network traffic to be redirected to an external probe for detailed analysis
When installed with the optional redundant power supply, there is no single point of failure due to power disruptions.
FUNCTIONAL SPECIFICATIONS
Ethernet Standards Supported
IEEE 802.1q VLAN support
IEEE 802.1d MAC Bridging (including STP)
IEEE 802.1p Quality of Service (QoS, Priority)
IEEE 802.1w Rapid Spanning Tree (RSTP)
IEEE 802.3 including:
• Fast Ethernet: IEEE 802.3u, 100Base-FX (Fiber)
• Gigabit Ethernet: IEEE 802.3z, 1000Base-X (Fiber)
• Gigabit Ethernet: IEEE 802.3ab, 1000Base-T (Copper)
Power
INTERNAL：AC Input power (auto-sensing) 100 V AC to 240 V AC, 50 to 60 Hz
EXTERNAL：Supports connection for redundant power supply
MAXIMUM POWER CONSUMPTION：66 Watts
MAXIMUM HEAT DISSIPATION：224 BTUs/Hr
MAXIMUM CURRENT：0.5 A at 110 V AC, 0.47 A at 220 V AC
ENVIRONMENTAL SPECIFICATIONS
TEMPERATURE：0° to +50°C (32° to +122°F)
RELATIVE HUMIDITY：5% to 95% (noncondensing)
TEMPERATURE：-40° to +70°C (-40° to +158°F)
RELATIVE HUMIDITY：5% to 95% (noncondensing)
PHYSICAL SPECIFICATIONS
Weight - Approximate：2.7 kg (5.95 lb)
Dimensions
HEIGHT 4.4 cm (1.7 in) WIDTH 44.1 cm (17.36 in) DEPTH 36.85 cm (14.5 in)
APPLICATIONS
• Simulation
• Instrumentation
• Industrial control
• Process control and monitoring
• Factory automation
• Intelligent networked PLC controllers
• Automated test
• Data acquisition
