UNIOP eX710 HMI  Ethernet Display control instrument
❤ Add to collection

UNIOP eX710 HMI Ethernet Display control instrument

+86-15305925923
Mr.Wang
wang@kongjiangauto.com

UNIOP eX710 HMI  Ethernet Display control instrument

28756.00
¥27740.00
Weight:4.000KG
Quantity:
(Inventory: 31)
Consultation
Product parameters
  • Telephone:+86-15305925923
  • contacts:Mr.Wang
  • Email:wang@kongjiangauto.com
Description

UNIOP eX710 HMI  Ethernet Display control instrument


UNIOP eX710 HMI  Ethernet Display control instrument

Italy EXOR-UNIOP HMI

Italy EXOR-UNIOP HMI has more than one hundred configurations, the product range includes entry-level text operator panel, colour graphic display, touch screen (desktop and handheld), advanced terminal graphic workstation four parts, its HMI communication technology is in the world's high-quality level, and it is the OEM of Siemens HMI, the products are widely used in the iron and steel, textile, printing and machinery industries. In addition, UNIOP has more than two hundred kinds of communication drivers, through the optional PLC modules, field or remote input/output modules can be connected to a variety of industrial equipment, including fieldbus networks and industrial Ethernet protocols, thus helping users save operating costs.

FEATURES

• 10.1” TFT color display, resolution 1280x800 pixel,  16M colors. Dimmable LED backlight

• Projected capacitive touchscreen. True glass design.  Multitouch operation

• 3 Ethernet ports

• SD Card slot

• 2 Plug-in modules for system expansion

Highlights

eX700 Series HMI products combine state-of-the-art connectivity features and top performance in a great design.  Products have been designed as IoT edge devices with the combination of a powerful controller with networking  capability and outstanding communication options including client/server OPC UA. They are the ideal choice for all  demanding IoT edge applications in factory, marine and building automation. The glass projected capacitive touchscreen and the brilliant 10.1” widescreen display with resolution of 1280x800  guarantee great optical performance; with the support of multitouch gesture programming they can create the most  natural human interfaces. eX Series 700 HMI products have been designed to run the JMobile software.

• JMobile runtime included

• Requires JMobile V2.6 or higher

• Supports Corvina Cloud secure connectivity with full network separation

• OPC UA Server and Client

• Optional CODESYS V3 runtime with choice of EtherCAT, Profinet, Ethernet IP and Powerlink

System Resources

Display - Colors:10.1“ TFT 16:9 LED - 16M

Resolution:1280x800, WXGA

Touchscreen:PCAP, Multitouch

CPU:32-bit RISC dual core - 800 MHz

Operating System:Linux RT

Flash:4 GB

Interface

Ethernet port:3 (port 0 - 10/100/1000, port 1 - 10/100, port 2 - 10/100)

USB port:2 (Host V2.0, max. 500 mA)

Expansion:2 slot for plug in modules

Power supply:24 Vdc (10 to 32 Vdc)

Current Consumption:1.0 A at 24 Vdc (max.)

Battery:Rechargeable Lithium battery, not user-replaceable

Environment Conditions

Operating Temperature:-20° to +60 °C (vertical installation). Plug-in modules and USB devices may limit  max temperature to +50 °C

Storage Temperature:-20°C to +70°C

Operating / Storage Humidity:5-85% RH, non condensing

Protection Class: IP66 (front), IP20 (rear) - Type: 12, 4X

Dimensions and Weights

Faceplate LxH:282x197 mm (11.10x7.80“)

Cutout AxB:271x186 mm (10.67x7.32“)
