DESCRIPTION

The Control Panels combine state-of-the-art features and top performance with an outstanding design. They are the ideal choice for all demanding HMI applications including factory and building automation.

These Control Panels have been designed to run the PB610 Panel Builder 600 software.

 PB610 Panel Builder 600 Runtime included. Full compatibility with PB610 Panel Builder 600.

 Full vector graphic support. Native support of SVG graphic objects. Transparency and alpha blending.

 Full object dynamics: Control visibility and transparency, move, resize, rotate any object on screen. Change properties of basic and complex objects.

 TrueType fonts.

 Multilanguage applications. Easily create and manage your applications in multiple languages to meet global requirements. Far East languages are supported. Tools available in PB610 Panel Builder 600 support easy third-party translations and help reducing development and maintenance costs of the application.

 Data display in numerical, text, bargraph, analog gauges and graphic image formats.

 Rich set of state-of-the-art HMI features: Data acquisition, alarm handling, scheduler and timed actions (daily and weekly schedulers, exception dates), recipes, users and passwords, e-mail and RSS feeds, rotating menus.

 Includes support for a set of communication drivers.

 Multiple drivers communication capability.

 Remote monitoring and control. Client-Server functionality.

 Offline and online Simulation with PB610 Panel Builder 600.

 Powerful scripting language for automating HMI applications. Script debugging improves efficiency in application development.

 Rich gallery of vector symbols and objects.

 Project templates.

Technical Specifications

Touchscreen technology：Resistive

Back-up battery：3V 50mAh Lithium, rechargeable, not user-replaceable, model VL2330

Fuse：Automatic

Serial Port：RS-232, RS-485, RS-422 software configurable

Recipe memory：Flash

Hardware clock：Clock/calendar with back-up battery

Accuracy RTC (at 25 °C operating)：< 100 ppm

Environmental Conditions

Operating temperature (surrounding air temperature)：0 °C … +50 °C for CP635-Fx: -20 °C … +60 °C

Storage temperature：-20 °C … +70 °C for CP635-Fx: -40 °C … +85 °C

Operating and storage humidity：5 % … 85 % RH not-condensing

Vibrations：5 Hz … 9 Hz, 7 mm p-p 9 Hz … 150 Hz, 1 g

Shock：± 50 g, 11 ms, 3 pulses per axis

CP635-FB, CP635-FW:

Main Features

 Stainless steel bezel 316/1.440l

 Food-compatible gasket

 Food standard sealing compliant with FDA 21 CFR 177.2006

 PCAP touchscreen, can be operated with gloves for food areas

 Designated according to DIN EN 1672-2

 Designated according to the EHEDG Guideline
