ABB CM572 PROFIBUS communication module Input/output module

ABB CM572 PROFIBUS communication module Input/output module

DESCRIPTION

ABB CM572 PROFIBUS communication module is a PROFIBUS communication module for industrial automation control system produced by ABB.ABB CM572 PROFIBUS communication module is a powerful and stable industrial automation communication module. ABB CM572 PROFIBUS communication module is a powerful and stable industrial automation communication module that can meet the needs of various industrial automation control systems.

Technical characteristics

·Communication protocol: Support PROFIBUS DP communication protocol, which is a bus communication protocol widely used in industrial automation.

·Extensibility: As a CPU extension module, CM572 can be easily connected to ABB's PLC (Programmable Logic Controller) to achieve communication with other devices that support PROFIBUS.

·Stable performance: ABB, as a leader in the field of industrial automation, produces communication modules with high performance and stability to meet the needs of various complex industrial environments.

Environmental conditions

Voltage：24 V (-15 %, +20 %)

Max. ripple：5 % from nominal value

Voltage：120 V (-15 %, +10 %)

Frequency：50/60 Hz (-6 %, +4 %)

DC supply：Interruption < 10 ms, time between 2 interruptions > 1 s, PS2

AC supply：Interruption < 0.5 periods, time between 2 interruptions > 1 s

Operating

-40 °C...+70 °C

-40 °C...-30 °C: Proper start-up of system; technical data not guaranteed

-40 °C...0 °C: Due to the LCD technology, the display might respond very slowly.

-40 °C...+40 °C: Vertical mounting of modules possible, output load limited to 50 % per group

+60 °C...+70 °C with the following deratings:

● System is limited to max. 2 communication modules per terminal base

● Applications certified for cULus up to +60 °C

● Digital inputs: maximum number of simultaneously switched on input channels limited to 75 % per group (e.g. 8 channels => 6 channels)

● Digital outputs: output current maximum value (all channels together) limited to 75 % per group (e.g. 8 A => 6 A)

● Analog outputs only if configured as voltage output: maximum total output current per group is limited to 75 % (e.g. 40 mA => 30 mA)

● Analog outputs only if configured as current output: maximum number of simultaneously used output channels limited to 75 % per group (e.g. 4 channels => 3 channels)

Application Scenarios

ABB CM572 PROFIBUS communication module is widely used in industrial automation control systems, including but not limited to the following scenarios:

●Production line automation: In manufacturing industry, it is used to connect various equipments on the production line to realise real-time transmission of data and sending of control commands.

●Robot control: cooperate with industrial robots to achieve communication between robots and PLC, improve production efficiency and flexibility.

●Process control: In chemical, petroleum, metallurgy and other industries, it is used to connect various process control equipments to achieve automation control of production process.

Precaution

●When purchasing and using the ABB CM572 PROFIBUS communication module, make sure that the selected module matches your PLC model and control system requirements.

●During installation and commissioning, please follow the installation guide and operation manual provided by ABB to ensure the normal operation of the module and system stability.

●If you encounter technical problems or need technical support, please contact ABB's customer service department or professional industrial automation technicians for advice and solutions.
