INTRODUCTION

REF 610 is a versatile multifunction protection relay mainly designed for protection of  incoming and outgoing feeders in MV distribution substations. REF 610 can also be used  as back-up protection for motors, transformers and generators, in industrial as well as in  utility applications.The large number of integrated protection  functions, including three-element overcurrent protection, two-element, non-directional  ground-fault protection as well as thermal  protection, makes REF 610 a complete protection against overcurrent and ground faults.

FEATURES

ï Three-phase non-directional overcurrent  protection with definite-time or IDMT  (mode) characteristic, low-set element

ï Three-phase non-directional overcurrent  protection with definite-time or instantaneous characteristic, high-set element

ï Three-phase non-directional overcurrent  protection with definite-time or instantaneous characteristic, instantaneous element

ï Non-directional ground fault protection with  definite-time, IDMT (mode) or instantaneous characteristic, low-set element

ï Non-directional ground-fault protection with  definite-time or instantaneous characteristic, high-set element

ï Three-phase thermal overload protection  for cables

ï Arc protection - two lens sensors for arc detection  (optional) - automatic reference level adjustment  based on backlight intensity

- arc detection via a remote light signal

ï Automatic reclosing 1...3 shots

ï Circuit-breaker failure protection

ï Trip counters for circuit-breaker condition  monitoring

ï Trip-circuit supervision with possibility to  route the warning signal to a signal output

ï Trip lockout function

ï Four accurate current inputs

ï User-selectable rated frequency 50/60 Hz

ï Three normally open power output contacts

ï Two change-over signal output contacts  and three additional change-over signal  output contacts on the optional I/O module

ï Output contact functions freely configurable for desired operation

ï Two galvanically isolated digital inputs and  three additional galvanically isolated digital  inputs on the optional I/O module

ï Disturbance recorder

- recording time up to 80 seconds

- triggering by one or several internal or  digital input signals

- records four analog channels and up to  eight user

-selectable digital channels

- adjustable sampling rate

ï Non-volatile memory for

- up to 100 event codes with time stamp

- setting values

- disturbance recorder data

- recorded data of the five last events with  time stamp

- number of AR shots and pickups/trips  for protection elements

- target messages and LEDs showing the  status at the moment of power failure

ï HMI with an alphanumeric LCD and  manoeuvring buttons

- eight programmable LEDs

ï Multi-language support

ï User-selectable password protection for  the HMI

ï Display of primary current values

ï Demand values

ï All settings can be modified with a PC

ï Optical front communication connection:  wirelessly or via cable

ï Optional rear communication module with  plastic fibre-optic, combined  fibre-optic (plastic and glass) or RS-485  connection for system communication  using the SPA-bus, IEC 60870-5-103 or  Modbus (RTU and ASCII) communication  protocol

ï Optional DNP 3.0 rear communication  module with RS-485 connection for system  communication using the DNP 3.0 communication protocol.

ï Battery back-up for real-time clock

ï Battery charge supervision

ï Continuous self-supervision of electronics  and software.

ï Detachable plug-in unit
