Bently 3500/42M Proximitor Seismic Monitor
Bently 3500/42M Proximitor Seismic Monitor
OVERVIEW
The 3500/42M Proximitor Seismic Monitor:
l Protects machinery by continuously comparing monitored parameters against configured alarm setpoints to drive alarms.
l Communicates essential machine information to both operations and maintenance personnel.
The 3500/42M Proximitor Seismic Monitor is a four-channel monitor that accepts input from proximity and seismic transducers. It conditions the signal to provide vibration and position measurements and compares the conditioned signals with user-programmable alarms.
Specifications Inputs
Signal:Accepts from 1 to 4 proximity, velocity or acceleration transducer signals
Power consumption:7.7 watts, typical
Standard I/O:10 kΩ (Proximitor and acceleration inputs)
Front Panel LEDs
OK LED:Indicates when the 3500/42M Proximitor Seismic Monitor is operating properly.
TX/RX LED:Indicates when the 3500/42M Proximitor Seismic Monitor is communicating with other modules in the 3500 rack.
Bypass LED:Indicates when the 3500/42M Proximitor Seismic Monitor is in Bypass Mode.
Output Impedance:550 Ω
Transducer Power Supply:-24 Vdc
Direct filter:-3 dB at 15.6 Hz
Gap filter:-3 dB at 0.41 Hz
Frequency Response
Bias:-3dB at 0.01 Hz Velocity II only
Not OK filter :-3 dB at 40 Hz Velocity II only
Peak or peakto-p
Compliance and Certifications
FCC
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
l This device may not cause harmful interference.
l This device must accept any interference received, including interference that may cause undesired operation.
